Butt’s Pumps and Motors - page 363

FEATURES:
- PSC
- THRU BOLT OR BELLY BAND MOUNTING
- 3 SPEED
- SLEEVE BEARING
Stock Motor
HP RPM Volts Amps Number Rot. Shaft Dia. Dia Notes
* 1/4 1075 115 4.8 3583 REV 1/2" 5.5"
* 1/4 1075 208-230 2.2 3584 REV 1/2" 5.5"
1/4 1625 115 2.7 3992 REV 1/2" 5.5"
1/4 1625 208-230 1.2 3993 REV 1/2" 5.5"
* 1/3 1075 115 5.9 3585 REV 1/2" 5.5"
* 1/3 1075 208-230 2.9 3586 REV 1/2" 5.5"
1/3 1625 115 3.9 3994 REV 1/2" 5.5"
1/3 1625 208-230 1.9 3995 REV 1/2" 5.5"
* 1/2 1075 115 7.7 3587 REV 1/2" 5.5"
* 1/2 1075 208-230 4.2 3588 REV 1/2" 5.5"
1/2 1625 115 6.0 3996 REV 1/2" 5.5"
1/2 1625 208-230 2.8 3997 REV 1/2" 5.5"
* 3/4 1075 115 10.5 3589 REV 1/2" 5.5"
* 3/4 1075 208 -230 5.4 3590 REV 1/2" 5.5"
3/4 1625 115 8.5 3998 REV 1/2" 5.5"
3/4 1625 208 -230 4.0 3999 REV 1/2" 5.5"
1075 115 11.8 3595 REV 1/2" 5.5"
1075 208-230 5.6 3596 REV 1/2" 5.5"
* SUGGESTED STOCK
FEATURES:
- PSC
- THRU BOLT OR BELLY BAND MOUNTING
- 3 SPEED
- SLEEVE BEARING
Stock Motor
HP RPM Volts Amps Number Rot. Shaft Dia. Dia Notes
* 1/2 - 1/6 1075 115 6.2 3463 REV 1/2" 5.5" FDL6001
* 1/2 - 1/6 1075 208-230 2.7 3464 REV 1/2" 5.5" FD6000
3/4 - 1/5 1075 115 8.5 3466 REV 1/2" 5.5" FDL6002
3/4 - 1/5 1075 208-230 4.2 3467 REV 1/2" 5.5" FD6001
* SUGGESTED STOCK
DIRECT DRIVE MOTORS
LIFE LINE STANDARD MULTI HORSEPOWER
7
www.air-con.ca Toll free (877) 564-8171
* 1
* 1
