FILE NO.: 6010.201
DATE: Apr. 16, 2008
SUPERSEDES: 6010.201
DATE: Sept. 14, 2005
ITEM
PART NUMBER
NO.
28 BODY GASKET
106050-000
12 BRACKET HOUSING
(2)
816963-111
8 COUPLER ASSEMBLY
(4 - Spring)
806026-001
22 FACEPLATE
116290-071
3 FLANGE - 1" NPT - BRONZE
116012-041
5 FLANGE BOLTS - 7/16-14X1 3/4
911123-114
4 FLANGE GASKET
105176-000
11 FLANGE NUTS - 7/16-14
913125-100
2 IMPELLER
116301-325
23 IMPELLER KEY (WOODRUFF #2)
974507-100
27 IMPELLER NUT
106076-000
26 IMPELLER WASHER
927311-700
15 MECHANICAL SEAL ASSEMBLY
816706-021
7
RESILIENT MTD. MOT. ASSY. - 1PH/1/6HP/115V
817025-001
10 MOTOR CAPSCREWS - 5/16-18x1
911118-108
17 O RING - MODULE
961131-036
18 O RING - REAR BEARING
961131-024
19 O RING - SHAFT
961131-013
24 OIL SEAL
116975-000
21 OIL WICK (BRIDGE)
116949-000
20 OIL WICK (ROUND)
116948-000
1 PUMP BODY
811240-041
9 PUMP BODY CAPSCREWS - 7/16-14x1
911123-108
29 SEAL BEARING ASSEMBLY
(1)
816027-002
16 SHAFT AND BEARING MODULE
(3)
816999-041
NOTES:
(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,
Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.
(2) Includes Face Plate and Buna "N" Oil Seal
(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,
rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup and 5/8 ounces of oil.
BAR CODE
MODEL NUMBER H41 - SIZE 4 - Serial No. 5710 & Later
ALL BRONZE CONSTRUCTION
DESCRIPTION
ARMSTRONG
CIRCULATOR PARTS
Circulator Parts List
20 of 113
