V-PULLEYS
FINISHED BORE • AK & BK
24
Stock Bores
Keyseats Stock Bores
Keyseats
1/2
None
1
1/4x1/8
9/16
1/8x1/16
1
1/16
1/4x1/8
5/8
3/16x3/32
1
1/8
1/4x1/8
11/16
3/16x3/32
1
3/16
1/4x1/8
3/4
3/16x3/32
1
1/4
1/4x1/8
13/16
3/16x3/32
1
3/8
1/4x1/8
7/8
3/16x3/32
1
3/8
1/4x1/8
15/16
1/4x
1
1/8
1
7/16
3/8x3/16
ISO STANDARD METHOD
FOR MEASURING KEYSEAT
DEPTH
Depth measured at centerline.
Reference:
1 inch=25.4 millmeters
1 millmeter=0.3937 inches.
W
D
Ref:Bore+D
• Manufactured in high quality grey cast iron
• Finished bore with H7 precision
• Keyway and set screws in accordance with USAS. B. 17.1-1967
• OEM surface treatment available: paint or black phosphate -
contact LEESON
• Individually packaged
AK & BK CAST IRON SHEAVES
STANDARD KEYSEATS
V PULLEYS
