40
A/B-C-D V-PULLEYS
FOR QTL TAPER BUSHING
A/B-1
F=1"
(25.40mm)
1 B 34 SH
3.00
3.40
3.75
SH
D
1
1
11/16
9/16
-
1
5/16
1/8
1.2
1 B 36 SH
3.20
3.60
3.95
SH
D
1
1
11/16
9/16
-
1
5/16
1/8
1.3
1 B 38 SH
3.40
3.80
4.15
SH
D
1
1
11/16
9/16
-
1
5/16
1/8
1.6
1 B 40 SH
3.60
4.00
4.35
SH
C
1
1
11/16
1/4
5/16
1
5/16
3/16
1.8
1 B 42 SH
3.80
4.20
4.55
SH
C
1
1
11/16
1/4
5/16
1
5/16
3/16
2.0
1 B 44 SH
4.00
4.40
4.75
SH
C
1
1
11/16
1/4
5/16
1
5/16
3/16
2.2
1 B 46 SDS
4.20
4.60
4.95
SDS
C
1
2
5/16
5/16
1
3/8
3/16
2.4
1 B 48 SDS
4.40
4.80
5.15
SDS
C
1
2
5/16
5/16
1
3/8
3/16
2.6
1 B 50 SDS
4.60
5.00
5.35
SDS
C
1
2
5/16
5/16
1
3/8
3/16
3.0
1 B 52 SDS
4.80
5.20
5.55
SDS
C
1
2
5/16
5/16
1
3/8
3/16
3.4
1 B 54 SDS
5.00
5.40
5.75
SDS
C
1
2
5/16
5/16
1
3/8
3/16
3.8
1 B 56 SDS
5.20
5.60
5.95
SDS
C
1
2
5/16
5/16
1
3/8
3/16
4.0
1 B 58 SDS
5.40
5.80
6.15
SDS
C
1
2
5/16
5/16
1
3/8
3/16
4.4
1 B 60 SDS
5.60
6.00
6.35
SDS
C
1
2
5/16
5/16
1
3/8
3/16
4.6
1 B 62 SDS
5.80
6.20
6.55
SDS
C
2*
2
5/16
5/16
1
3/8
3/16
4.8
1 B 64 SDS
6.00
6.40
6.75
SDS
C
2*
2
5/16
5/16
1
3/8
3/16
5.0
1 B 66 SDS
6.20
6.60
6.95
SDS
C
2*
2
5/16
5/16
1
3/8
3/16
5.4
1 B 68 SDS
6.40
6.80
7.15
SDS
C
2*
2
5/16
5/16
1
3/8
3/16
5.6
1 B 70 SDS
6.60
7.00
7.35
SDS
C
2*
2
1/2
1/8
1
3/8
1/8
6.0
1 B 74 SDS
7.00
7.40
7.75
SDS
C
2*
2
1/2
1/8
1
3/8
1/8
6.3
1 B 80 SDS
7.60
8.00
8.35
SDS
C
3
2
1/2
1/8
1
3/8
1/8
6.6
1 B 86 SDS
8.20
8.60
8.95
SDS
C
3
2
1/2
1/8
1
3/8
1/8
7.0
1 B 94 SDS
9.00
9.40
9.75
SDS
C
3
2
1/2
1/8
1
3/8
1/8
8.0
1 B 110 SDS
10.60
11.00
11.35
SDS
C
3
2
1/2
1/8
1
3/8
1/8
10.0
1 B 124 SDS
12.00
12.40
12.75
SDS
C
3
2
1/2
1/8
1
3/8
1/8
12.0
1 B 136 SDS
13.20
13.60
13.95
SDS
C
3
2
1/2
1/8
1
3/8
1/8
14.0
1 B 154 SK
15.00
15.40
15.75
SK
C
3
2
5/8
9/16
1/8
1
15/16
3/8
17.0
1 B 160 SK
15.60
16.00
16.35
SK
C
3
2
5/8
9/16
1/8
1
15/16
3/8
18.0
1 B 184 SK
18.00
18.40
18.75
SK
C
3
2
5/8
9/16
1/8
1
15/16
3/8
20.0
1 B 200 SK
19.60
20.00
20.35
SK
C
3
2
5/8
9/16
1/8
1
15/16
3/8
23.0
Part No.
P.D.
O.D.
Bush
Type
E
K
L
M
A Belt
B Belt
Bush
Max.
Bore
Wgt.
Less
Bush
COMBINATION GROOVE
D. D
"A"
BELTS
D. D.
"B"
BELTS
D-1
C-1
C-3
F
L
K
E
P.D.
O.D.
M
K
F
E
P.D.
O.D.
L
M
K
F
E
P.D.
O.D.
L
M
FOR QTL TAPER BUSHING - SEE PAGE 10
A/B-C-D
* Contact LEESON for drawing
TM
®
