FILE NO.: 6010.201
DATE: Apr. 16, 2008
SUPERSEDES: 6010.201
DATE: Sept. 14, 2005
ITEM
NO.
35
BEARING ASSEMBLY (1)
35
BEARING ASSEMBLY KIT C/W Seal Kit & Cover Plate (2)
10 BEARING BRACKET
4
BEARING CAP ASSEMBLY (3)
3 BEARING CAP CAPSCREWS 1/4-20X5/8
29 BODY
21 BODY CAPS. - 3/8-16X7/8
28 BODY GASKET
2 COUPLER ASSEMBLY (Flexible) 5/8X5/8
15 COUPLER GUARD
0 COUPLER INSERT
7 COUPLER KEY (Woodruff #9)
20 COVERPLATE (Bronze)
18 COVERPLATE CAPSCREWS 5/16-18X3/4
31 FLANGE - 3" NPT - (Bronze)
32 FLANGE BOLTS - 5/8-11X2 1/2
30 FLANGE GASKET
-
FLANGE NUTS - 5/8-11
25 IMPELLER (Brass) 5 7/8"
8 IMPELLER KEY (WOODRUFF #3)
27 IMPELLER NUT 7/16-20NF (Bronze)
26 IMPELLER WASHER
15 MECH. SEAL ASSY. (Brass Buna)
15 MECH. SEAL ASSY. (Brass Viton High Temp. 225F-275F)
14 OIL LEVEL WINDOW
9 OIL SLINGER
12 OIL WELL COVER ASSEMBLY
11 OIL WELL COVER GASKET
-
OIL WICKS (3/8X1/2)
1
RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V (4)
17 RES. MTD. MTR. CAPSCREWS 3/8-16X5/8 (4 Req'd)
1
RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V (4)
1
RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V (4)
1
RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V (4)
17 RIGID MT. MTR. CAPSCREWS 3/8-16X7/8 (4 Req'd)
6 SHAFT & SLEEVE ASSEMBLY
6 SHAFT & SLEEVE ASSY. ( S/S Sleeve)
19 WATER SLINGER
NOTES:
(1) Bearing Assembly does not include Coverplate, Mechanical Seal Assembly, Ceramic Seat or Retainer Cup.
(2) Bearing Assembly Kit includes B/F Coverplate, Mechanical Seal Assembly, Ceramic Seat and Retainer Cup.
(3) 874112-000 Brg/Cap assy.Kit includes Brg/Cap Assy., "O" Ring, Oil Seal & Oil Wick.
(4) For TEFC or Explosion Proof Motors, contact the factory.
PART NUMBER ARMSTRONG
BAR CODE
816366-041
816861-041
816342-011
874112-000
911117-105
816354-071
CIRCULATOR PARTS
MODEL NUMBER S69 - SIZE 6 Serial No. 6505 & Later
ALL BRONZE CONSTRUCTION
DESCRIPTION
816339-041
911121-107
106592-000
816665-000
116114-000
875000-801
974515-100
816346-041
911119-106
106074-041
911129-120
105201-000
913129-100
816308-042
974508-100
116406-000
927412-700
816707-001
116904-001
116369-000
116361-000
816707-003
116400-000
816565-000
811757-007
911121-106
816676-062
816676-069
811757-009
911121-107
116368-000
816354-041
Circulator Parts List
85 of 113
