FILE NO.: 6010.201
DATE: Apr. 16, 2008
SUPERSEDES: 6010.201
DATE: Sept. 14, 2005
ITEM
PART NUMBER
NO.
28 BODY GASKET
106158-000
12 BRACKET HOUSING (2)
816966-111
8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2
807436-000
8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8
806137-000
0 COUPLER INSERT
875000-800
22 FACEPLATE
174003-071
3 FLANGE - 2" NPT - CAST IRON
106074-011
5 FLANGE BOLTS - 1/2-13X2 1/4
911125-120
4 FLANGE GASKET
105176-000
11 FLANGE NUTS - 1/2-13
913125-118
2
IMPELLER - 5 1/4" DIA. (See note 4)
816304-317
2
IMPELLER - 4 3/4" DIA. (See note 4)
816304-321
2
IMPELLER - 4" DIA. (See note 4)
816304-327
23 IMPELLER KEY (WOODRUFF #2)
974507-100
27 IMPELLER NUT
106076-000
26 IMPELLER WASHER
927311-700
15 MECHANICAL SEAL ASSEMBLY
816706-021
7
RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115/230V
816141-002
7
RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V
(5)
830590-083
7
RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115/230V
811757-001
7
RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V
(5)
831011-083
7
RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V
(5)
831011-083
7
RESILIENT MTD. MOT. ASSY. - 1PH/3/4HP/115/230V
811757-002
7
RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/208/230/460V
(5)
831012-083
7
RIGID MOUNT. MOT. ASSY. - 3PH/3/4HP/575V
(5)
811757-006
7
RESILIENT MTD. MOT. ASSY. - 1PH/1HP/115/230V
811757-007
7
RIGID MOUNT. MOT. ASSY. - 1PH/1HP/115/230V
(5)
816676-062
7
RIGID MOUNT. MOT. ASSY. - 3PH/1HP/208/230/460V
(5)
816676-069
7
RIGID MOUNT. MOT. ASSY. - 3PH/1HP/575V
(5)
811757-009
10 MOTOR CAPSCREWS - 3/8-16X3/4
911121-106
17 O RING - MODULE
961131-036
18 O RING - REAR BEARING
961131-024
19 O RING - SHAFT
961131-013
24 OIL SEAL
116975-000
21 OIL WICK (BRIDGE)
116949-000
20 OIL WICK (ROUND)
116948-000
1 PUMP BODY
816338-011
9 PUMP BODY CAPS. - 5/16-1/8x3/4
911123-108
29 SEAL BEARING ASSEMBLY (1)
816032-000
16 SHAFT AND BEARING MODULE (3)
816999-041
NOTES:
(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,
Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.
(2) Includes Face Plate and Buna "N" Oil Seal
(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,
rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup and 5/8 ounces of oil.
(4) Impeller Part Numbers are for stock diameter Impellers. For Impeller Diammeters not listed, please contact the
factory.
(5) For TEFC or Explosion Proof Motors, please contact the factory.
BAR CODE
CIRCULATOR PARTS
MODEL NUMBER 1050 2B - SIZE 5 Serial No. 6208 & Later
STANDARD AND BRONZE FITTED CONSTRUCTION
DESCRIPTION
ARMSTRONG
Circulator Parts List
79 of 113
