Series 5200 and 5240 sump and 5400 sewage systems are available in simplex and duplex column configu-
rations. These systems are designed to meet a wide range of medium and heavy-duty industrial and commer-
cial applications such as: waste water removal, unscreened sewage, condensate transfer, bilge water, and
drainage runoff. Armstrong Sump and Sewage systems are available with cast iron volutes and choices of
iron or bronze impellers as well as steel or stainless steel shafts. They provide reliable and efficient perform-
ance and can be configured with a variety of accessories and options.
Systems
f
Sump and Sewage Systems
The Armstrong chilled water line of Integrated Plant Package (IPP-CHW) systems bring cus-
tomers today's most energy efficient solution for the 150 to 1080 ton (60 Hz) or 500 to 3600
kW (50 Hz) range.
Available for exterior installation with full enclosure or mechanical room installation, the IPP-CHW
solution brings about a new way of constructing a facility. The IPP-CHW solution is a pre-fabricated
factory-built solution, optimized for quick installation with future service needs in mind. All IPP-CHW
solutions incorporate Armstrong VIL Series 4300 pumps, Turbocor
TM
oil-free frictionless compressors,
and Armstrong IPC 11550 ultra-efficient chilled water plant control systems. This packaged solution
provides important benefits for the end user including:
f
Operating plant efficiencies of less than 0.5 kW/ton or COP of 7.3 (on an annual average basis)
f
Remote monitoring and control through a web-based interface, for mutli-facility operation
f
Lubricant (oil) free compressor operation (reduces maintenance time and lubricant costs)
f
Extremely quiet operation from the Turbocor
TM
(less than 75 dBA) compressor and the VIL pumps
f
Extraordinarily low vibration levels from the VIL pumps and Turbocor
TM
compressor
f
Easy access to components
f
Superior user interface for capturing operation data or fine-tuning system parameters
The IPP-CHW solution is available as a variable primary flow configuration. Units can be configured to include a variable flow
cooling tower, or a cooling tower can be connected on-site separately.
f
Integrated Plant Package (IPP-CHW)
Armstrong’s expertise in systems engineering benefits everyone concerned with fluid flow and HVAC demand.
Armstrong engineered systems provide uniform water supply, reduced costs and reduced floor space require-
ments. The systems include sump and sewage, pressure booster, fire pump, heat transfer and condensate. Many of
our systems are available in standard and custom package configurations, with horizontal and VIL pump options.
Armstrong is one of the world’s leading manufacturers of packaged pressure booster systems.
Decades of experience in the design of custom packages ensure uniform water supply, reduced
costs and reduced floor space requirements. Systems are available in a range of configurations
from simplex to quintuplex, with vertical pumps, for continuous or intermittent operation. System
part-load conditions are managed effectively by Armstrong's variable speed system controls.
f
Pressure Booster Systems
Armstrong fire pump systems are constructed in accordance with the requirements of
Underwriters Laboratories Inc. (UL), Underwriters Laboratories of Canada (ULC), and Factory
Mutual Research Corporation (FM). Our fire pumps and packaged fire systems comply with
recommendations of the National Fire Production Association (NFPA) Pamphlet 20. System
configurations are available with either horizontal end suction, horizontal split case or vertical
pumps and with either an electric or diesel driver.
f
Fire Pump Packaged Systems
