FILE NO.: 6010.201
DATE: Apr. 16, 2008
SUPERSEDES: 6010.201
DATE: Sept. 14, 2005
ITEM
NO.
28 BODY GASKET
12 BRACKET HOUSING
(2)
8 COUPLER ASSEMBLY
(4 - Spring)
806026-001
22 FACEPLATE
116077-071
3 FLANGE - 3/4" NPT - CAST IRON
116013-011
3 FLANGE - 1" NPT - CAST IRON
116012-011
3 FLANGE - 1 1/4" NPT - CAST IRON
116011-011
3 FLANGE - 1 1/2" NPT - CAST IRON
116009-011
5 FLANGE BOLTS - 7/16-14X1 1/2
911123-112
4 FLANGE GASKET
816653-000
11 FLANGE NUTS - 7/16-14 JAM
911123-112
2 IMPELLER
812961-111
23 IMPELLER KEY (WOODRUFF #2)
974507-100
27 IMPELLER NUT
913171-100
26 IMPELLER WASHER
927311-100
15 MECHANICAL SEAL ASSEMBLY
816706-021
7
RESILIENT MTD. MOT. ASSY. - 1PH/1/12HP/115V
805316-010
10 MOTOR CAPSCREWS - 1/4-20X5/8
911117-105
17 O RING - MODULE
961131-036
18 O RING - REAR BEARING
961131-024
19 O RING - SHAFT
961131-013
24 OIL SEAL
116975-000
21 OIL WICK (BRIDGE)
116949-000
20 OIL WICK (ROUND)
116948-000
1 PUMP BODY
805482-011
9 PUMP BODY CAPSCREWS- 3/8-16X7/8 911121-107
29 SEAL BEARING ASSEMBLY
(1)
810119-001
16 SHAFT AND BEARING MODULE
(3)
816999-071
NOTES:
(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 812961-111 Impeller,
Standard 106076-000 Impeller Nut, Standard 927411-700 Impeller Washer, Module, Impeller Key,
"Armite" Seal Assembly, Ceramic Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.
(2) Includes Face Plate and Buna "N" Oil Seal
(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,
rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup and 5/8 ounces of oil.
MODEL NUMBER S25 - SIZE 2 - Serial No. 6205 & Later
STANDARD AND BRONZE FITTED CONSTRUCTION
104442-000
BAR CODE
CIRCULATOR PARTS
DESCRIPTION
ARMSTRONG
PART NUMBER
816958-111
Circulator Parts List
4 of 113
