170
1/4 x 5/16 Bushing
(1/4" x 5/16" Bush)comes with 1/4" x 5/16
Bushing
2 Spd-Plug
2 Speed Motor with Special Plug or
Leads
2Pt (2 Point Mount)
2 Extended Bolts and Tapped Holes on
Front or Back of Motor
2Pt-4Pt Mount
Motor has 4 Extended Studs & 2 or 4 may
be used for Mounting
3Pt (3 Point Mount)
3 Extended Bolts or 3 Tapped Holes on
Back of Motor
3Pt Wire Mt
Motor has 3 Holes in the Side to Fit in
Special Wire Bracket
A.
Automatic Overload Protection
A.A.
All Angle Mounting (Vertical Up, Vertical
Down or Horizontal)
All
Stud, Strap or Base Mounting
Ball
(B) Ball Bearing
B.C.
Bolt Circle
C Ring Groove
Groove Cut in Shaft for Positioning C
Ring Clip
C.C.W.
Counter Clockwise Rotation
C.F.
Condenser Fan
C.S.
Capacitor Start
C.W.
Clockwise Rotation
C/W
Complette With
Capacitor Included
(Cap.Incl.) Motor Shipped with Capacitor
Case Bolt
Motor Assembly Bolts Extended for
Mounting
Conduit Box
Conduit Box Attached to Motor for
Electrical Connections
Cont. Duty
Continuous Duty
Cooling Ring
External Rings Attached to Motor to
Assist Heat Dissipation
Cut Offs
Cuts in Shaft for Exact Positioning and
Ease of Cutting
Dble Brkt
(Double Bracket) Bracket Welded to
Motor
E.F.
Mounting Ears Flush to End of Motor
E.R.
Mounting Ears Recessed from End of
Motor
F
Flat on Shaft
F.C.
Fan Canopy
Flange
Flange Mounting
Fleck Plug
Rectangular Plug with Round Pins
Flex
Flex Mounting
Grooved Shaft
Shaft has a Groove Cut for Positioning
H.H.
Hex Hubs
H.V.A.C
.
Heating Ventilation and Air Conditioning
Hayco Plug
Round Plug and Round Pins for Electrical
Connection
Inc
.
Included
Internal Fan
(Int.Fan) Motor has Fan Inside for
Additional Cooling Purposes
K
Keyed Shaft
K.F.
Keyed Shaft with Flat
L-K Fitting
For Attaching Conduit Connector
Left Hand Thread
Shaft has Thread to Screw on Plastic
Fan with a Slot in End
Leg Mount
Motor has Feet with Holes Drilled and
Tapped
Lyall Plug
Round Plug with Round Pins for
Electrical Connection
Notched Shaft
Shaft has a Flat Cut in it
O.D
.
Open Drip Construction
P.S.C.
Permanent Split Capacitor
Pad/Leg
Pad Mount or Leg Mount
Pad Mount
Motor has Mounting Hole in Rear Part
of
the Body
Panel
Panel Mounting
Plug
2 or 3 Prong Plug
R.A.C.
Room Air Conditioning
R.P.
Reversing Plug
R.S.
Rain Shield
Rev.
Reversible
Ring Term
Round Eyelet Terminal
Sleeve
(S) Sleeve Bearing
S.E.
Semi-Enclosed Construction
S.F.
Service Factor
S.P.
Shaded Pole
S.S.
Stud or Strap Mounting
SPD/RPM
Number of Speeds and the Highest
R.P.M.
St
.
Strap Mounting
Spades
Spade Terminals Supplied
Speed Control
Motor with Additional Lead to be Used
with
a Variable Speed Control
Split
Split Phase
Stud Mount
Bolts of Motor Extend for Mounting
Switch & Cord
Motor has Off/On Switch C/W Cord and
Plug Assembly
T.B.
Triangle Bracket
T.E.
Totally Enclosed Construction
THR Shaft
Threaded Shaft-Thread at End of Shaft
for Plastic Impellor
Terminals
Spade or Other - Terminals Included in
Box
Triangle Brkt
Triangle Bracket with Rubber Grommets
Mounted on Front or Back
U Bracket
(U Brkt) Bracket Attached to Motor
V.D.
Vertical Down Mounting
V.U.
Vertical Up Mounting
Vertical Mt
Motor has Special Lubrication System
for Shaft Up Operation
Watts
(W) Wattage
Worm Gear
Gear Attached to Shaft as Drive Unit
Throughout this catalogue certain terms and phrases have been abbreviated.
Below is a list of these abbreviations and their meanings.
Motor Catalogue Terminology
