160
Mounting Bases
Motor Mounting Brackets
Lug Mounting Bracket
Part # Motor Dia.
Min. Bolt
Circle Dia
Max Bolt
Circle Dia
Lug Size
92-A8379
3 3/8"
4 5/8"
5 7/8" Small - 1 3/4"
92-A8380
3 3/8"
5 7/8"
9 7/8"
Large - 4"
92-A8377
4 1/4"
5 1/2"
6 3/4" Small - 1 3/4"
92-A8378
4 1/4"
6 3/4"
10 3/4"
Large - 4"
92-A8320
5"
6 5/16"
7 9/16" Small - 1 3/4"
92-A8366
5"
7 9/16" 11 9/16"
Large - 4"
92-A8323
5 5/8"
6 7/8"
8 1/8" Small - 1 3/4"
92-A8364
5 5/8"
8 1/8"
12 1/8"
Large - 4"
Anti - Windmill Brake
Vibration Insulators
Part #
Description
92-AW12
For 1/2" Shaft
92-AW58
For 5/8" Shaft
Part # Karmen #
Max. Load in Pounds
Compression Shear
92-A7801
K-30
60
-
92-A7802
K-33
100
-
92-A7803
K-40
25
13
92-A7804
K-44
40
10
Part # Karmen #
Max. Load in Pounds
Compression
Shear
92-A7805
K-47
50
10
92-A7806
K-130
60
-
92-A7807
K-133
100
-
A7801
A7802
A7803
A7804
A7805
A7806
A7807
1.625”
0.88”
1.187”
0.88”
0.624”
0.624”
1.50”
5/8”UNCTHD
1.187”
1.00”
1.625”
0.624”
0.624”
5/8”UNCTHD
0.88”
0.88”
1.00”
0.88”
5/16”
1.00”
0.42”
0.42”
1.00”
5/8”
1.00”
0.88”
0.624”
0.624”
5/8”
1.00”
0.75”
0.88”
0.47”
0.47”
1/4” 20THD
1/4” 20THD
3.187”
1.60”
1.50”
0.624”
0.88”
5/16”
1.25”
1.56”
1.00”
0.88”
0.624”
5/16”
Motor Mounting & Accessories
