Introduction
SECTION
PAGE
DATE
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
3
INTRO
www.cranepumps.com
Model Nomenclature Chart
For Submersible Pumps
3 30 SE 3 2 L
†
DISCHARGE SIZE:
* = 1.25" Discharge
* = 1.50" Discharge
2 = 2" Discharge
3 = 3" Discharge
NAMEPLATE HORSEPOWER:
5 = 0.5HP
20 = 2HP
50 = 5HP
MOTOR, PHASE & VOLTAGE:
0=200 Volt ,1 Phase,60 Hz.
1=115 Volt ,1 Phase,60 Hz.
2=230 Volt ,1 Phase,60 Hz.
3=230 Volt ,3 Phase,60 Hz.
4=460 Volt ,3 Phase,60 Hz.
5=575 Volt ,3 Phase,60 Hz.
6=200 Volt ,3 Phase,60 Hz.
7=200/230 Volt ,1 Phase,60 Hz.
8=230/460 Volt, 3 Phase,60 Hz.
9=200/230 Volt, 3 Phase,60 Hz.
T=380 Volt, 3 Phase, 60Hz.
V=415 Volt, 3 Phase, 50 Hz.
W=110 Volt, 1 Phase, 50 Hz.
X=220 Volt, 1 Phase, 50 Hz.
Y=220 Volt, 3 Phase, 50 Hz.
Z=380 Volt, 3 Phase, 50 Hz
SERIES PUMP:
BP = Sump/Effluent
EH = Effluent
EHV = Effluent-Vortex
PGPP = Vortex Submersible Grinder
SE = Sewage Ejector
SEV = Sewage Ejector-Vortex
STEP = Septic Tank Effluent Pump
SF = Submersible Fountain
SFU = Submersible Fountain
SP = Sump/Effluent
UT = Utility
SPEED:
60Hz (50Hz)
2=3450RPM (2850)
4=1750RPM (1425)
6=1150RPM (950)
8=870RPM (720)
DESIGN CODE:
A=Automatic (Swing type level control)
AU=Automatic (Swing type level control)
DS=Double Seal Oil Filled
HT=High Temperature
L =Oil Filled
S=Special
SS=Single Seal Oil Filled
VF=Vertical level control
X=Cord length variation
(*) Discharge designation is not used on these models.
(†) This model nomenclature does not apply to the following submersible Non-Clog pumps:
SE411, SE421, SE411HT, SE51, SE52, SE51HT, SE52HT & UT17.
THE FOLLOWING MODEL NOMENCLATURE IS USED IN SECTIONS B AND C.
