Butt’s Pumps and Motors - page 323

SECTION
PAGE
DATE
Submersible Fountain Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
10
H
Professional Plumbing
Series
3SF-HD
Heavy Duty
4/04
inches
(mm)
IMPORTANT !
1.)
DO NOT USE TO PUMP FLAMMABLE LIQUIDS
.
2.) NSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A
COMMON OCCURRENCE.
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D.
inch (mm)
3SF1524HD 110952 1.5
230/1 60 1750
B
12.6
23.0
10/3
SO 0.690 (17.5)
3SF2024HD 110953 2.0
230/1 60 1750
B
14.5
29.0
10/3
SO 0.690 (17.5)
