Cross Reference
This information is furnished as a guide only. Always check specific motor to determine suitability for direct replacement.
AC SUB-FHP GEARMOTOR CROSS REFERENCE
PZ SERIES AC GEARMOTORS: Parallel Shaft
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Dayton Bodine Baldor Bison
2 100 1/150 M1125050 6Z074 — — 016-103-2362
9 100 1/15 M1125127* 6Z076 0449 GCP24114 016-103-2186
19 100 1/15 M1125128* 6Z081 0448 GCP24122 016-103-1096
28 100 1/15 M1125129* 6Z082 0455 GCP24124 —
57 56 1/15 M1125130* 6Z083 0454 GCP24134 016-103-1025
94 36 1/15 M1125131* 6A197 0453 — 016-103-1019
142 24 1/15 M1125132* — 0452 — 016-103-1013
283 12 1/15 M1125133* — 0451 — —
P240 SERIES AC GEARMOTORS: Parallel Shaft
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Dayton Bodine Baldor Bison
8 345 1/15 M1145029 6Z816 0476 GCP24004 016-226-6215
15 250 1/15 M1145023 4Z518 0485 — —
16 391 1/6 M1145030 6Z817 0485 — 016-226-6102
30 135 1/15 M1145024 4Z519 — — —
30 295 1/6 M1145031 6Z818 0484 — 016-226-6058
40 219 1/6 M1145032 6Z819 0483 GCP25052 016-226-6036
45 92 1/15 M1145025 4Z520 — — —
60 157 1/6 M1145033 6Z820 0482 GCP25054 016-226-6028
70 61 1/15 M1145026 4Z521 — — —
90 103 1/6 M1145034 6Z821 0481 GCP25056 016-226-6019
97 43 1/15 M1145027 4Z522 — — —
139 30 1/15 M1145028 4Z523 0480 — —
156 60 1/6 M1145035 6Z822 — GCP25060 016-226-6011
RIGHT-ANGLE AC GEARMOTORS
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Dayton Bodine Baldor Bison
28 37 1/15 M1125080 IL536 0492 — —
43 34 1/15 M1125081 IL538 0491 GC24310~ —
58 40 1/15 M1125082 IL535 0487 — —
85 24 1/15 M1125083 IL534 0490 GC24306~ —
173 14 1/15 M1125084 IL533 0488 GC24302~ —
29 110 1/6 M1145037 IL501 — — —
43 113 1/6 M1145038 IL502 0678 GC25020~ —
57 95 1/6 M1145082 IL503 — GC25015~ 026-756-8030
83 75 1/6 M1145039 IL504 0677 GC25010~ 026-756-8020
170 43 1/6 M1145040 IL505 0672 — 026-756-8010
340 23 1/6 M1145041 — 0670 — 026-756-8005
~Mounting base and output shaft height are not ‘drop-in’ replacement.
Some Dayton and all Baldor right-angle gearmotors have double output shafts.
* ÎxäÊ- , -Ê Ê , "/",-ÊUÊ- Ê* - \Ê*>À>iÊ- >vÌ
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Baldor Bodine Bison Dayton
5 310 1/12 096000 — 0671 016-246-6254 6MK70
9 341 1/12 096001 — 0669 016-246-6170 6MK71
14 330 1/12 096002 GCP9320 0636* — 6MK72
19 250 1/12 096003 GCP9322 0635* 016-246-6082 6MK73
29 270 1/6 096004 — 0685 016-246-6058 6MK74
34 250 1/6 096005 — — — 6MK75
40 180 1/6 096006 — 0654* — 6MK76
59 135 1/6 096007 GCP3305 0683 016-246-6028 6MK77
75 90 1/6 096008 — 0681 016-246-6023 6MK78
113 68 1/6 096009 — 0651* 016-246-6015 6MK79
160 45 1/6 096010 GCP3315 0680 016-246-6011 6MK80
340 25 1/6 096011 GCP3320 0679 016-246-6005 6MK81
*Split Phase Type
* ÎxäÊ Ê/",+1 ÊUÊ- Ê* - \Ê >«Ê-Ì>ÀÌ
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Baldor Bodine Bison Dayton
58 320 1/3 096049 GLP3330 0664* — —
85 218 1/3 096050 GLP3332 0663* — —
173 109 1/3 096051 GLP3336 0662* — —
345 55 1/3 096052 GLP3338 0662* — —
*Split Phase Type
*££ääÊ- , -Ê Ê , "/",-ÊUÊ- Ê* - \Ê*>À>iÊ- >vÌ
F.L. Cross Reference
Output Torque Ratio Input LEESON
RPM (lb.in.) to 1 HP Catalog No. Dayton Bison*
8 975 212 1/4 107000 6Z400 014-482-4211
12 1030 143 1/4 107004 6K351 014-482-4143
18 800 95 1/4 107003 6Z401 014-482-4095
26 569 66 1/4 107002 6K352 —
59 248 29 1/4 107005 6K353 014-482-4029
133 114 13 1/4 107001 6K354 014-482-4011
18 1089 95 1/3 107006 6Z402 014-482-3095
26 752 66 1/3 107012 6K396 014-482-3066
41 461 42 1/3 107011 2Z842 014-482-3042
59 330 29 1/3 107010 6K369 014-482-3029
91 224 19 1/3 107009 2Z843 014-482-3019
157 125 11 1/3 107008 2Z844 014-482-3011
288 70 6 1/3 107007 2Z845 014-482-3006
22 1105 79 1/2 107013 6Z403 —
41 700 42 1/2 107017 6K375 014-482-2042
59 496 29 1/2 107016 6K583 014-482-2029
91 336 19 1/2 107015 6K383 014-482-2019
133 229 13 1/2 107014 6K506 014-482-2011
* Bison units are split phase design.
*££ääÊ- , -Ê Ê , "/",-ÊUÊ/ , Ê* - \Ê*>À>iÊ- >vÌ
F.L. Cross Reference
Output Torque Ratio Input LEESON
RPM (lb.in.) to 1 HP Catalog No. Dayton Bison
18 1089 95 1/3 107025 6Z404 —
26 752 66 1/3 107026 4Z384 —
41 461 42 1/3 107027 4Z385 —
59 330 29 1/3 107028 4Z386 —
91 224 19 1/3 107029 4Z387 —
157 125 11 1/3 107030 4Z388 —
288 70 6 1/3 107031 4Z389 —
22 1105 79 1/2 107032 6Z405 017-482-0095
41 700 42 1/2 107033 4Z390 017-482-0042
59 496 29 1/2 107034 4Z391 017-482-0029
91 336 19 1/2 107035 4Z392 017-482-0019
133 229 13 1/2 107036 4Z393 017-482-0011
288 100 6 1/2 107037 4Z394 017-482-0006
Application Notes:
P1100 AC gearmotors have the same mounting dimensions as Bison 482 gearmotors and Dayton gearmotors.
For additional information, see Bulletin 1830.
* These motors are TEFC.
* ÎxäÊ- , -Ê Ê , "/",-ÊUÊ/ , Ê* - \Ê*>À>iÊ- >vÌ
F.L. Cross Reference
Output Torque Input LEESON
RPM (lb.in.) HP Catalog No. Baldor Bodine Bison Dayton
58 320 1/3 096013 GMP3330 0666 017-246-0029 6MK82
85 218 1/3 096014 GMP3332 0642 017-246-0019 6MK83
173 109 1/3 096015 GMP3336 0665 017-246-0011 6MK84
345 55 1/3 096016 GMP3338 — 017-246-0005 6MK85
