227
Information
(8 holes on 225S & M)
4 Holes Through S Dia.
B5 FLANGE
B14 FACE
METRIC (IEC) FRAME DIMENSIONS (Millimeters)
Frame
Mounting
Shaft
General
B5 Flange
B14 Face
A
B
C
H AB
K
D
E
F
G
ED
DH
AC
AD
HD
M
N
P
S
T
LA
M
N
P
S
T
LA
D56
90 71 36
56 107 6
9
20
3
7.5
8
M3 x 8
–
–
–
100
80
120
7
2.5
7
65
50
80
M5
2.5
7
D63
100 80 40
63 122 7
11
23
4
8.5
10
M4 x 10
126
84
171
115
95
140
10
3.0
7
75
60
90
M5
2.5
7
D71
112 90 45
71 136 7
14
30
5
11.0 20
M5 x 12.5 141
94
191
130 110
160
10
3.5
7
85
70
105
M6
2.5
9
D80
125 100 50
80 154 10
19
40
6
15.5 25
M6 x 16
159 102 206
165 130
200
12
3.5
12
100
80
120
M6
3.0
9
D90S
140 100 56
90 172 10
24
50
8
20.0 32
M8 x 19
180 112 229
165 130
200
12
3.5
12
115
95
140
M8
3.0
9
D90L
140 125 56
90 172 10
24
50
8
20.0 32
M8 x 19
180 112 229
165 130
200
12
3.5
12
115
95
140
M8
3.0
9
DF100L 160 140 63 100 205 12
28
60
8
24.0 40
M10 x 22 205 130 270
215 180
250
15
4.0
11
130
110 160
M8
3.5
14
DF112M 190 140 70 112 230 12
28
60
8
24.0 40
M10 x 22 240 150 300
215 180
250
15
4.0
12
130
110 160
M8
3.5
11
DF132S 216 140 89 132 270 12
38
80
10 33.0 56
M12 x 28 275 180 345
265 230
300
15
4.0
12
165
130 200 M10
3.5
14
DF132M 216 178 89 132 270 12
38
80
10 33.0 56
M12 x 28 275 180 345
265 230
300
15
4.0
12
165
130 200 M10
3.5
14
DF160M 254 210 108 160 320 15
42 110
12 37.0 80
M16 x 36 330 210 420
300 250
350
19
5.0
13
215
180 250 M12
4.0
13
DF160L 254 254 108 160 320 15
42 110
12 37.0 80
M16 x 36 330 210 420
300 250
350
19
5.0
13
215
180 250 M12
4.0
13
DF180M 279 241 121 180 355 15
48 110
14 42.5 80
M16 x 36 360 236 455
300 250
350
19
5.0
15
–
–
–
–
–
–
DF180L 279 279 121 180 355 15
48 110
14 42.5 80
M16 x 36 360 236 455
300 250
350
19
5.0
15
–
–
–
–
–
–
DF200L 318 305 133 200 395 19
55 110
16 49.0 100 M20 x 42 420 260 505
350 300
400
19
5.0
18
–
–
–
–
–
–
DF225S 356 286 149 225 435 19 55*/ 110*/ 16*/ 49*/ 100*/
M20 x 42 450 275 580
400 350
450
19
5.0
18
–
–
–
–
–
–
60 140
18
53 125
DF225M 356 311 149 225 435 19
55*/ 110*/ 16*/ 49*/ 100*/
M20 x 42 450 275 580
400 350
450
19
5.0
18
–
–
–
–
–
–
60 140
18
53 125
DF250M 406 349 168 250
24
60*/ 140*/ 18*/ 53*/ 125*/
M20 x 42 508 300 625
–
–
–
–
–
–
–
–
–
–
–
–
65 140
18
58 125
* 2 Pole Dimensions
The overall length dimension for each catalog item is listed on pages 148-151 of this catalog.
Frames DF100L through DF132M, conduit box is located in the center of the frame.
B3 FOOT-MOUNTED
DIMENSIONS
AC METRIC (IEC) MOTORS
