232
Information
DIMENSIONS
SPEEDMASTER
®
INVERTER MOTORS
/ 6ÊUÊ Ê
ÊUÊ, Ê - ÊUÊ
- " -Ê V
iî
Frame
D
E
2F
H
O
P
U
AA
AB
AG
AH
AJ
AK
BA
BB
BF
BS
KEY
Size
MAX.
MAX.
MAX.
MAX.
143TC
3.50
2.75
4.00
.38
7.45
7.98
.875
1.09
7.04
9.25
2.12
5.875
4.50
2.62
.13
3/8-16 2.81 .19 x .19 x 1.38
145TC
3.50
2.75
5.00
.35
7.45
7.98
.875
1.09
7.04
10.25
2.12
5.875
4.50
2.62
.13
3/8-16 3.81 .19 x .19 x 1.38
182TC
4.50
3.75
4.50
.41
9.36
9.76
1.125 1.09
8.08
11.75
2.62
7.250
8.50
3.50
.27
1/2-13 2.25 .25 x .25 x 1.75
184TC
4.50
3.75
5.50
.41
9.36
9.76
1.125 1.09
8.08
12.75
2.62
7.250
8.50
3.50
.27
1/2-13 2.75 .25 x .25 x 1.75
213TC
5.25
4.25
5.50
.44
10.97 11.50 1.375 1.09
9.31
15.12
3.12
7.250
8.50
4.25
.27
1/2-13 3.50 .31 x .31 x 2.38
215TC
5.25
4.25
7.00
.44
10.97 11.50 1.375 1.09
9.31
17.31
3.12
7.250
8.50
4.25
.27
1/2-13 6.18 .31 x .31 x 2.38
254TC
6.25
5.00
8.25
.53
14.09 14.27 1.625 1.25
9.83
19.06
3.75
7.250
8.50
4.75
.27
1/2-13 6.31 .38 x .38 x 2.88
256TC
6.25
5.00
10.00
.56
14.09 14.27 1.625 1.25
11.08 18.82
3.75
7.250
8.50
4.75
.27
1/2-13 5.00 .38 x .38 x 2.88
284TC
7.00
5.50
9.50
.56
14.16 14.32 1.875 1.50
12.31 20.57
4.38
9.000 10.50 4.75
.27
1/2-13 5.50 .50 x .50 x 3.25
TENV—C FACE, RIGID BASE
TEBC—TOTALLY ENCLOSED BLOWER COOLED, RIGID BASE
/ ÊUÊ/"/ 9Ê "- Ê "7 ,Ê "" ÊUÊ, Ê - ÊUÊ
- " -Ê V
iî
Frame
D
E
2F
H
O
P
U
AA
AB
AC
BA
BS
FU
N-W
KEY
Size
MAX.
MAX.
MAX.
MAX.
325T
8.00
6.25
10.50
.66
16.00
15.88
2.12
2.00
13.69
10.69
5.25
5.25
1.00
5.25
.50 x .50 x 3.88
326T
8.00
6.25
12.00
.66
16.00
15.88
2.12
2.00
13.69
10.69
5.25
6.00
1.00
5.25
.50 x .50 x 3.88
364T
9.00
7.00
11.25
.66
19.00
20.00
2.38
3.62
17.85
14.56
5.88
5.62
1.00
5.88
.62 x .62 x 4.25
365T
9.00
7.00
12.25
.66
19.00
20.00
2.38
3.62
17.85
14.56
5.88
6.12
1.00
5.88
.62 x .62 x 4.25
404T
10.00
8.00
12.25
.81
20.88
21.75
2.88
3.62
18.75
14.75
6.62
6.12
1.00
7.25
.75 x .75 x 5.62
405T
10.00
8.00
13.75
.81
20.88
21.75
2.88
3.62
19.75
16.25
6.62
6.88
1.00
7.25
.75 x .75 x 5.62
444T
11.00
9.00
14.50
.81
24.19
25.31
3.38
3.62
20.94
17.38
7.50
7.25
1.00
8.50
.88 x .88 x 6.88
445T
11.00
9.00
16.50
.81
24.19
26.31
3.38
3.62
20.94
17.38
7.50
8.25
1.00
8.50
.88 x .88 x 6.88
449T
11.00
9.00
25.00
.81
24.22
26.31
3.38
4.62
25.90
19.31
7.50
1.78
1.00
8.50
.88 x .88 x 6.88
