FILE NO.: 6010.201
DATE: Apr. 16, 2008
SUPERSEDES: 6010.201
DATE: Sept. 14, 2005
ITEM
PART NUMBER
NO.
28 BODY GASKET
106158-000
12 BRACKET HOUSING (2)
816966-111
8 COUPLER ASSEMBLY (Flexible) 1 PHASE 1/2X1/2
807436-000
8 COUPLER ASSEMBLY (Flexible) 3 PHASE 1/2X5/8
806137-000
0 COUPLER INSERT
875000-800
22 FACEPLATE
174003-071
3 FLANGE - 1 1/4" NPT - BRONZE
116011-041
5 FLANGE BOLTS - 7/16-14X1 3/4
911125-120
4 FLANGE GASKET
105176-000
11 FLANGE NUTS - 7/16-14 JAM
913125-100
2
IMPELLER (Brass) - 5 1/4" DIA. (See note 5)
816302-047
2
IMPELLER (Brass) - 4 3/4" DIA. (See note 5)
816302-051
2
IMPELLER (Brass) - 4 3/8" DIA. (See note 5)
816302-054
2
IMPELLER (Brass) - 4" DIA. (See note 5)
816302-057
23 IMPELLER KEY (WOODRUFF #2)
974507-100
27 IMPELLER NUT
106076-000
26 IMPELLER WASHER
927311-700
15
MECHANICAL SEAL ASSY. (Viton) (4)
816706-023
7 RESILIENT MTD. MOT. ASSY. - 1PH/1/4HP/115V
816141-001
7 RIGID MOUNT. MOT. ASSY. - 3PH/1/4HP/208/230/460V
(6)
830781-083
7 RESILIENT MTD. MOT. ASSY. - 1PH/1/3HP/115V
816141-002
7 RIGID MOUNT. MOT. ASSY. - 3PH/1/3HP/208/230/460V
(5)
830590-083
7 RESILIENT MTD. MOT. ASSY. - 1PH/1/2HP/115V
811757-001
7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/208/230/460V
(5)
831011-083
7 RIGID MOUNT. MOT. ASSY. - 3PH/1/2HP/575V
(5)
831011-083
10 MOTOR CAPSCREWS - 3/8-16X3/4
911121-106
17 O RING - MODULE
961131-036
18 O RING - REAR BEARING
961131-024
19 O RING - SHAFT
961131-013
24 OIL SEAL
116975-000
21 OIL WICK (BRIDGE)
116949-000
20 OIL WICK (ROUND)
116948-000
1 PUMP BODY
816337-041
9 PUMP BODY CAPS. - 5/16-1/8x3/4
911123-108
29
SEAL BEARING ASSEMBLY (1) & (4)
816032-000
16
SHAFT AND BEARING MODULE (3) & (4)
816999-041
NOTES:
(1) Seal Bearing Assembly includes Bearing Bracket, Body Gasket, Standard 106076-000 Impeller Nut,
Standard 927411-700 Impeller Washer, Module, Impeller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup, and 5/8 Ounces of Oil.
(2) Includes Face Plate and Buna "N" Oil Seal
(3) Includes Front Sleeve Bearing, Shaft and Sleeve Assembly, two Oil Wicks, three "O" Rings,
rear Sleeve Bearing Assembly, four Mounting Screws, Impelller Key, "Armite" Seal Assembly,
Ceramic Seal Seat, Buna "L" (retainer) Cup and 5/8 ounces of oil.
(4) The 816706-021 Mechanical Seal on the Universal SBA and the Shaft & Bearing Module must be removed and
replaced with a 816706-023 Viton High Temperature Mechanical Seal.
(5) Impeller Part Number is for a full diameter Impeller. Always specify the Pump Serial Number and if
possible the diameter of the impeller being replaced.
(6) For TEFC or Explosion Proof Motors, contact the factory.
BAR CODE
MODEL NUMBER 1050 11/4B - SIZE 5 Serial No. 6208 & Later
HIGH TEMP. ALL BRONZE CONSTRUCTION ( 225 - 275 DEG. F )
DESCRIPTION
ARMSTRONG
CIRCULATOR PARTS
Circulator Parts List
73 of 113
