211
Electrical
120 & 240 Volt
Part #
Volts Watts
Insert
Length
Water Type Reference
Watts @
208
39-S1500-1
120 1500 6 1/2"
Normal / Hard
1
-
39-S1500
240 1500 6 1/2"
Normal / Hard
1
1150
39-S3001
240 3000 9"
Normal
1
2250
39-S3000
240 3000 8 1/2"
Normal /
Hard
2
2250
39-S3000L
240 3000 10 3/4"
Normal /
Hard
2
2250
39-S4000
240 4000 11 3/16" Normal /
Hard
2
3000
39-S4500
240 4500 11"
Normal
1
3500
39-S4500L
240 4500 13 1/8"
Normal /
Hard
2
3500
39-S5000
240 5000 13 1/8"
Normal /
Hard
2
3800
39-S6000
240 6000 10 3/4"
Normal
2
4500
Other wattages, watt densities, and incoloy models available upon requests.
120 & 240 Volt
Part #
Volts Watts
Insert
Length
Water Type Reference
Watts @
208
39-F1500-1
120 1500 6 15/16" Normal / Hard
3
-
39-F1500
240 1500 8 7/16" Normal /
Hard
3
1150
39-F3000
240 3000 9 7/16" Normal
3
2250
39-F3000L
240 3000 8 9/16" Normal /
Hard
4
2250
39-F3800
240 3800 9 7/16" Normal
3
2850
39-F4500
240 4500 11 7/16" Normal
3
3400
39-F4500L
240 4500 13 7/16" Normal /
Hard
4
3500
39-F5000
240 5000 8 9/16" Normal
4
3800
39-F6000
240 6000 11 3/16" Normal
4
4500
Other wattages, watt densities, and incoloy models available upon requests.
Figure 1.
Straight
Figure 3.
Hairpin
Figure 4.
Fold Back
Figure 2.
Fold Back
Watt Density Reference
Water Type
Watt Density
Normal
High/ Medium Density
Hard Medium/ Low Density
Hard
Low Density
Screw-In Flange Water Heating Elements
1" Non Tapered Brass Plug - Screw-In Flange (Residential)
• 0.312" Diameter Element.
• Zinc Plated Copper.
• UL & CSA Listed.
• Individually Packaged.
• Includes Gasket (39-10546-001).
• Adapter Kit To Convert To Square Flange.
2 1/2" Square - Bolt-On Flange (Residential)
• 0.312" Diameter Element.
• Zinc Plated Copper.
• UL & CSA Listed.
• Individually Packaged.
• Includes Gasket (39-692-004).
Square Bolt-On Flange Water Heating Elements
Watt Density Reference
Water Type
Watt Density
Normal
High/ Medium Density
Hard Medium/ Low Density
Hard
Low Density
Water Heater Components
