Electrical
Thermostats - Temporary Construction Site
Construction Thermostats
Three wire installation
Switched fan, 3 modes:
• Fan Only
• Off
• Heat or Cool
Part #
Description
78-SC060S
60°F w/ switch - fan/off/ heat.
78-SC065S
65°F w/ switch - fan/off/ heat.
78-SC070S
70°F w/ switch - fan/off/ heat.
78-SC075S
75°F w/ switch - fan/off/ cool.
Construction Thermostats
Two Wire Installation.
Part #
Description
78-SC055
55°F cool.
78-SC060
60°F heat.
78-SC065
65°F heat.
78-SC070
70°F heat.
78-SC075
75°F cool.
Specifications
Electrical Rating
• 24 volt AC (18-30 VAC)
• 2 amp maximum
Temperature Control Ranges
• Accuracy ±5°F 55°, 60°, 65°, 70°, 75°F
"Dry Out" Thermostats
Temporary Construction Site Thermostats
• The 78-SC055 to 78-SC075S series of thermostats are low cost
single set point thermostats intended for temporary heating or
cooling to allow drywall to dry during construction. Can also be
used for low ambient cut-off switch.
• Rugged utility thermostat for temporary applications.
• Ideal for new or ongoing construction areas.
• Five fixed set point models to choose from (55°, 60°, 65°, 70°, 75°F).
• Hardwired.
Thermostat Accessories
Wall Plates
• Perfect for those installations where
you need more wall coverage.
• Rugged, flexible construction.
• Foam gasket prevents drafts through
wall opening.
• Hidden mounting screws (included) for
a sleek appearance.
Simple Comfort Thermostat Wall Plates
Two convenient sizes to choose from.
Part #
Description
78-ACCWP01
4 27/32" × 5 15/16".
78-ACCWP02
5 19/32" × 7 1/2".
Remote Sensor
• Designed for 78-SC3801 thermostats.
• Designed to monitor the temperature
remotely or away from the thermostat.
• For tamper-prone areas.
• Poor air flow areas.
• Troubled applications.
• Foam gasket prevents drafts through
wall opening.
Simple Comfort Remote Sensor
• Designed to work with the 78-SC3801.
• Mounts to standard 2" × 4" outlet box.
Part #
Description
78-RT104
• 2 3/4" × 4 1/2".
• Terminations: S1, S2.
78-ACCWP
Series
78-RT104
Series
78-SC075
Illustrated
78-SC075S
Illustrated
Applications
Ideal for warehouses!
