204
Electrical
Broil Elements
37-UT077
U
2500W/240V
W -11.00" L - 14.55" I - 1.875"
Straight Screw Terminals
37-UT095
U
3000W/240V
W - 11.00" L - 14.55" I - 1.875"
Straight Screw Terminals
37-UT096
U
3000W/240V
W - 11.00" L - 16.05" I - 1.875"
Straight Screw Terminals
37-UT097
U
3000W/240V
W -11.00" L - 16.55" I - 3.875"
Screw Terminals
37-UT120
*
3400W/240V
W - 11.88" L - 16.44" I - 2.875"
90° Spade Terminals
Replaces ET-075-105-106-145,
AM002-038
TIBK 40010-001
Replaces ET-116-117-125-175, RB-164, AM002-
006, AM002-009, 902360, 902363
TIBK 40010-002
Replaces ET-135-147-155-156, RB-426, AM002-
005, AM002-010, 902212, 902359
TIBK 40010-003
Replaces ET-149-265
TIBK 40010-004
Replaces 211806-1010,
211806-1020 Frigidaire U Bracket
TIBQ 40016-001
37-UT316
U
3000W/240V
W - 13.00" L - 15.05" I - 1.875"
Straight Screw Terminals
37-UT317
U
3000W/240V
W - 13.00" L - 16.55" I - 3.875"
Straight Screw Terminals
37-UT076
D
2500W/240V
W - 11.00" L - 14.00" I - 1.875"
Straight Screw Terminals
37-UT306
D
2400W/240V
W - 13.00" L - 14.00" I - 3.875"
Straight Screw Terminals
37-UT315
D
2500W/250V
W - 14.56" L - 14.50" I - 1.50"
Straight Spade Terminals
Replaces ET-215-225-245-285-315-317-325-465,
RB-168, AM002-002, 902357
TIBK 40011-001
Replaces ET-295-455, RB-225,
AM002-011, 902356
TIBK 40011-002
Replaces AM002-003,
902358, ET 165
TIBK 40012-001
Replaces EB-415, ET-305, RB-221-240,
AM002-011, 902364, 902367
TIBK 40012-002
Replaces 9780993,
21142 U Bracket
TIBK 21142-001
Legend
Bracket Style
* - 6 Hole Bracket
D - Double Bracket
GE - GE Style Bracket
OEM - OEM Bracket
U - Universal
Dimensions
W- Element Width
L - Element Length
I - Element Insert
Element Style
UB - Bake
UT - Broil
Straight Screw Terminal
Straight Spade Terminal
90° Spade Terminal
Bake & Broil
Terminal Connections
Universal Bracket
U
Comes With 37-FG Gasket
5"
2"
6 Hole Bracket
*
4"
1.75"
Original GE Style Bracket
GE
4"
1.875"
3.625"
0.875"
OEM Bracket
OEM
3.5"
1.80"
Double Bracket
D
3.5"
2"
Bake & Broil Elements
