Sump Pumps
1
A
www.cranepumps.com
Professional Plumbing
12/12
Series SU
Automatic
Submersible Sump
DISCHARGE ............................... 1½” NPT, Female, Vertical
LIQUID TEMPERATURE .............104°F (40°C) Continuous
MOTOR HOUSING ......................Cast Iron
PUMP BODY, STRAINER, IMPELLER:
......................................................Thermoplastic
SHAFT ........................................Steel
O-RINGS ...............................Buna-N
HARDWARE ................................300 Series Stainless Steel
PAINT ........................................... Air Dry Enamel
SEAL: Design ....................Single Mechanical, Type 11A
Material ................... Carbon/Ceramic/Buna-N
Hardware ................ 300 Series Stainless
CORD ENTRY..............................9 ft. (2.7m) Cord with plug and
Pressure Gromment for sealing and strain
relief
BEARINGS ................................Single Row, Ball, Oil Lubricated
MOTOR: Design ....................Oil Filled
Insulation................. Class B
SINGLE PHASE...........................Permanent Split Capacitor (PSC).
Includes thermal overload protection in
motor
LEVEL CONTROL .......................Vertical Float Integral to Pump
MINUMUM SUMP DIA .................14" ( 355mm)
NOTE............................................GFCI Compatible to Comply with NEC
210.8 (A)
Series: SU25, SU33
1/4 & 1/3HP, 3450RPM, 60Hz
DESCRIPTION:
PUMP FOR RESIDENTIAL SUMP APPLICATIONS
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
CSA 108
UL 778
LR16567
C US
This product may be covered by one
or more of the following patents and
other patent(s) pending:
US Patent 8,167,578
