Sump Pumps
9
A
Professional Plumbing
Series SP33VFAL
1/2" Spherical Solids Handling
Automatic w/Alarm, Submersible Sump /Effluent
Series: SP33VFAL,
1/3HP, 3450RPM, 60Hz
DESCRIPTION:
GENERAL PURPOSE PUMP FOR RESIDENTIAL AND
LIGHT INDUSTRIAL SUMP APPLICATIONS
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
DISCHARGE ...................................
1½” NPT, Female, Vertical
LIQUID TEMPERATURE ................
104°F (40°C) Continuous
MOTOR HOUSING ............................
Cast Iron
PUMP STRAINER .............................
Thermoplastic
IMPELLER:
Design
......................
10 Vane vortex, with pump out vanes on back
side. Balanced, ISO G6.3
Material
.....................
Cast Iron
SHAFT
..............................................
Stainless Steel
O-RINGS ............................................
Buna-N
HARDWARE ......................................
300 Series Stainless Steel
PAINT .................................................
Air Dry Enamel
SEAL:
Design
.......................
Single Mechanical, Type 21
Material
......................
Carbon/Ceramic/Buna-N
Hardware -300 Series Stainless
CORD ENTRY....................................
10 ft. (3m) or 20 ft. (6m) Cord with plug and
Pressure gromment for sealing and strain relief
UPPER BEARING..............................
Single Row, Ball, Oil Lubricated
LOWER BEARING.............................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
.......................
Oil Filled
Insulation
....................
Class B
SINGLE PHASE.................................
Permanent Split Capacitor (PSC).
Includes thermal overload protection in motor
LEVEL CONTROL .............................
Vertical float, PVC, snap action, 10 ft (3m)
or 20 ft. (6m) cord and integrated battery
operated alarm (P/N: 124886) with 6 ft. (1.8m)
cord. (See Section E page 10 for Alarm)
MINUMUM SUMP DIA .......................
12" (305mm)
NOTE..................................................
GFCI Compatible to Comply with NEC
210.8 (A)
CSA 108
UL 778
LR16567
C US
7/11
