Sump Pumps
11
A
Professional Plumbing
Series SP33HT
High Temperature - 1/2" Spherical Solids Handling
Manual & Automatic, Submersible Sump /Effluent
9/10
DISCHARGE ...................................
1½” NPT, Female, Vertical
LIQUID TEMPERATURE ................
185°F (85°C) Continuous, Fully Submerged
MOTOR HOUSING ............................
Cast Iron
PUMP STRAINER .............................
Stainless
IMPELLER:
Design
......................
10 Vane vortex, with pump out vanes on back
side. Balanced, ISO G6.3
Material
.....................
Cast Iron
SHAFT
..............................................
Stainless Steel
O-RINGS
..................................
Buna-N
HARDWARE ......................................
300 Series Stainless Steel
PAINT .................................................
Air Dry Enamel
SEAL:
Design
.......................
Single Mechanical, Type 21
Material
......................
Carbon/Ceramic/Buna-N
Hardware -300 Series Stainless
CORD ENTRY....................................
20 ft. (6m) Cord with plug and Pressure
Gromment for sealing and strain relief
UPPER BEARING..............................
Single Row, Ball, Oil Lubricated
LOWER BEARING.............................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
.......................
Oil Filled
Insulation
.................
Class B
SINGLE PHASE.................................
Permanent Split Capacitor (PSC).
Includes thermal overload protection in motor
MINUMUM SUMP DIA:
SP33HT...................... 12" (305mm)
NOTE..................................................
GFCI Compatible to Comply with NEC
210.8 (A)
Series: SP33HT
1/3HP, 3450RPM, 60Hz
DESCRIPTION:
GENERAL PURPOSE PUMP FOR RESIDENTIAL AND
LIGHT INDUSTRIAL SUMP APPLICATIONS
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
