Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Fan Coil DC ECMMotors
The
Comfort Select~FC
motor is a brushless DC
high efficiency motor that runs off a 120 volt single
phase input. The motor is controlled by integrated
electronics providing advanced motor protection
with the same performance characteristics as a
shaded pole or PSC motor. The
Comfort Select~FC
is designed as a direct replacement or retrofit product
for shaded pole and PSC motors and may be used in
fan coil and PTAC* applications as an energy saving
retrofit.
Fan Coils • Air Conditioners • Blowers • Shaded Pole • PSC Retrofit
Trane • Carrier • Amana • GE • Fan Coil & PTAC Units
Features
• Drop-in replacement
• Single Phase
• Brushless DC
• 3 Speeds
• 5 1/8" diameter
• 54" lead length
• Energy efficient
Benefits
• ECM with internal control
• Long life ball bearings
• Rotors are isolated from shaft to
reduce motor vibration
• Saves an average of 69% on
energy usage
• Runs cooler
• Easy to install
Part #
Volts
HP
Speeds Rotation Amps
RPM
Range
Shaft
Frame
M4-R2189
120
1/10
3
CWLE
1.56
1100,900,700 9.3" × 1/2" x 9.3"
42
