Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Unit Bearing ECMMotors
Unit Bearing Replacement For 3.3" Diameter
Heatcraft Replacement Motors - Bohn, Chandler, Climate Control and Larkin
ECM Unit Bearing Replacement For GE OEM 44 Frame, 58mm
Features
• Advanced ECM design
• More than 60% efficient
• Operating temperature:
-20°F(-29°C) to 104°F(40°C)
• 16" Leads with Lyall plug
• Cast iron
• Shaft down & horizontal mounting
Features
• Advanced ECM design
• More than 60% efficient
• Operating temperature:
Evaporator fan duty only
-20°F(-29°C) to 40°F(4°C)
• 16" Leads with Lyall plug
• Cast iron
• Shaft vertical up & horizontal mounting
Part #
HP
Amps
Volts Rotation RPM
Shaft
A Dim.
O4-R6355
1/15
1.25
115
CCW 1550
1.95" × 5/16"
3.2"
O4-R6350
1/15
1.25
115
CW
1550
1.95" × 5/16"
3.2"
O4-R6365
1/15
0.77
230
CCW 1550
1.95" × 5/16"
3.2"
O4-R6360
1/15
0.77
230
CW
1550
1.95" × 5/16"
3.2"
O4-R6375
1/10
1.35
115
CCW 1550
2.60" × 5/16"
4.4"
O4-R6370
1/10
1.35
115
CW
1550
2.60" × 5/16"
4.4"
O4-R6385
1/10
0.50
230
CCW 1550
2.60" × 5/16"
4.4"
O4-R6380
1/10
0.50
230
CW
1550
2.60" × 5/16"
4.4"
Part #
Watts
Amps
Volts
Rotation RPM Shaft
A Dim.
O4-R5443
9
0.45
115
CW
1650
1/4" × 20
2.78"
O4-R5444
16
0.55
115
CW
1850
1/4" × 20
2.78"
This
Replaces
This
