Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Reduce your carbon foot print and electricity bill at the
same time. Become more environmentally friendly! The
ECM series allows efficiency rates up to 70%, 4-5 times
more efficient than a traditional shaded pole fan motor.
Higher efficiency means cooler motor operation, longer
bearing expected life and reduced heat delivered to the
refrigeration cycle, for a combined energy saving advantage
and improved refrigeration quality.
The ECM-IP Series is widely used in industrial and
commercial refrigeration for condensing and evaporating
units, food and beverage coolers, freezers, supermarket
display cases, walk-ins and reach-ins.
Refrigeration ECMMotors
Features
Increased life:
Life expectancy of 60,000+ hrs.
with our sealed ball bearing option.
Moisture protection:
The ECM series offers IP65 & IP66
moisture protection grade, one of
the highest in the industry.
Wide range of CFM:
Choose among three different
factory preset RPM options and a
wide range of fan blades from 6
to 10 inches diameter and various
pitches, to satisfy all CFM needs.
Multiple mounting:
Compatible with ELCO’s standard
accessories, giving higher flexibility
in motor mounting. Installation on
a shroud, a grid or a mounting
bracket.
Drop in replacement:
The ECM-IP Series motor is a direct
drop-in replacement to our shaded
pole motor (NU series) for an easy
and hassle free “green turn”.
Modular Design
Designed to mount ELCO standard
(and third party) or integrated design
fan blades, for extreme application
flexibility and to cover a wide range
of performance requirements.
Compact design:
The ECM compact design with
its integrated plastic fan blade is
ideal for reduced space depth
applications.
Stock #
Watt Volt RPM Amp
ELCO OEM #
Type A dim.
Cord
length
Term. /
Plug.
EC-HE-0147
12 115 1450 0.18
EDA12153UC0147
A
3.61"
14"
3pin 90°
EC-HE-0170
12 115 1450 0.18
EDA12153UN0170
B
3.62"
14"
3pin 90°
EC-HE-0176
15 115 1600 0.22
EDA15253UC0176
A
4.00"
16"
2pin 90°
EC-HE-0182
10 115 1550 0.19
EDA10153UC0182
A
3.61"
16"
2pin 90°
Cross Reference
Part #
OEM Name
OEM #
EC-HE-0147
Arneg Canada & US
34410013 , 34410009, 24681010
EC-HE-0170
Arneg Canada & US
34410012 (for fan 34415010)
EC-HE-0176
Hill Phoenix
P078449H
EC-HE-0182
Hill Phoenix
P079441C, P066237A
'Type A'
'Type B'
