29
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
6.5" Condenser Fan Motors
Single & Three Phase
Three Phase
Part # HP Voltage Amps Encl.
RPM Rot. A Dim. Bearing Shaft
Base
Comment
M5-T2532
1/2
460/200-230 1.3/2.8-2.6 Open OSE 1/1140 Rev 10.31"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8280
Climate Master, Dunham Bush,
X500
M5-T2533
1/2
575
1.0
-
1/1075 Rev 8.10"
Ball
5.0" × 5/8"
Keyed & Flat
92-A8280
Climate Master, Dunham Bush,
SPL
M5-T2529
1/2
575
0.8
TEAO 1/1140 Rev 9.12"
Ball
3.44" × 5/8"
Keyed & Flat
-
H977
M5-T2534
3/4
460/200-230 1.5/2.8-3.0 Open OSE 1/1140 Rev 10.31"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8279
Keeprite, York, Trane, Carrier,
Lennox, H567
M5-T2535
3/4
575
1.25 Open OSE 1/1140 Rev 10.31"
Ball
6.0" × 5/8"
Keyed & Flat
-
M5-T2537
1
460/200-230 2.0/4.4-4.0 Open OSE 1/850 Rev 9.36"
Ball
4.88" × 5/8"
Keyed & Flat
92-A8281
Blanchard Ness, Hussmann, SPL
M5-T2539
1
575
1.6
Open OSE 1/850 Rev 10.25"
Ball
3.31" × 5/8"
Keyed & Flat
-
Blanchard Ness, Hussmann, H962
M5-T2538
1
460/200-230 2.6/5.3-5.2 Open OSE 1/1140 Rev 10.81"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8283
Keeprite, York, Trane, Carrier,
Lennox, H667
M5-T2540
1
575
2.0
Open OSE 1/1140 Rev 10.31"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8283
Keeprite, York, Trane, Carrier,
Lennox, X522
M5-T2542
1 1/2
460/200-230 3.0/5.8-6.0 Open OSE 1/1140 Rev 10.81"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8282
Keeprite, York, Trane, Carrier,
Lennox, H767
M5-T2543
1 1/2
575
2.3
Open OSE 1/1140 Rev 10.81"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8282
Keeprite, York, Trane, Carrier,
Lennox, H963
M5-T2544
2
460/208-230 7.2
-
1/1140 Rev 11.1"
Ball
5.0" × 5/8"
Keyed & Flat
-
Cancoil, X509
M5-T2545
2
460/208-230 3.1/6.8-6.2 Open OSE 1/1140 Rev 12.00"
Ball
3.63" × 5/8"
Keyed & Flat
-
70°C Ambient
M5-T2536
2
575
2.7
-
1/1140 Rev 11.1"
Ball
5.0" × 5/8"
Keyed & Flat
-
Cancoil, X526
Single Phase
Part # HP Voltage Amps Cap. RPM Rot. A Dim. Bearing Shaft
Base
Comment
M5-S1450
1/2
230
2.7 10/370 1/825 Rev 8.6"
Ball
6.1" × 5/8"
Keyed & Flat
92-A8279
Trane, Carrier, Climatrol, York, X208
M5-S1452
3/4
460-200-230 1.9/4.0 10/370 1/1075 Rev 10.25"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8280
Trane, Carrier, Climatrol, York, X207
M5-S1454
1
460/200-230 2.4/4.8 25/370 1/1075 Rev 10.75"
Ball
6.0" × 5/8"
Keyed & Flat
92-A8279
Trane, Carrier, Climatrol, York, C770
M5-S1451
1
575
2.2 25/370 1/1075 Rev 11.31"
Ball
6.0" × 5/8"
Keyed & Flat
-
M5-S1456
1 1/2
460/200-230 3.3/6.6 25/370 1/1075 Rev 12.06"
Ball
6.0" × 5/8"
Keyed & Flat
-
Trane, Carrier, Climatrol, York, C771
• Auto Protector
• Service Factor 1.0
• Class B Moisture-Resistant Ins.
• Double Sealed Ball Bearing
• 60°C Ambient
• 60 Hz
• 1" (Min.) Extended Thru Bolts
• Quick-Connect Design
• Auto Protector
• Class B Moisture-Resistant Insulation
• Double Sealed Ball Bearing
• Quick-Connect Design
• Service Factor 1.0
• 60°C Ambient
• 60 Hz
