Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Features
• Multi-Rating Cap Supplied
• North American Made
• Less Inventory Required!
• Versatile!
• Time Saver!
• Easy Installations!
• Energy Efficient
• Different Capacitor/Speed Combos
• Designed for 370V Cap
• Reversible Rotation
• Extended Thru Bolts
• Automatic Protector
• Class B Insulation
• Continuous Duty-Over Air
• Mounts by Belly Band, Thru Bolts or Shell Holes
• Rheem Mounting Holes in Shell
• 60 Hz
Totally Enclosed
Air Over - 60°C Ambient
Part # HP Spd.
RPM Volt Amps
Cap.
(370V)
Bearing Leads Body Shaft
208V 230V
M2-R22601
1/3
High
825 208-230
1.9
10 mfd 7.5
Ball
36"
5.24" 1/2"×5"
1/4
1.5
1/5
Low
1.2
1/6
1.0
M2-R22603
1/2
High
825 208-230
2.4
12.5 mfd 10
Ball
36"
5.61" 1/2"×6"
1/3
1.7
1/4
Low
1.4
1/5
1.1
M2-R22600
1/3
High
1075 208-230
2.8
7.5 mfd 5
Sleeve
36"
4.86" 1/2"×6"
1/4
2.0
1/5
Low
1.7
1/6
1.5
M2-R22605
1/3
High
1075 208-230
2.8
7.5 mfd 5
Ball
36"
4.86" 1/2"×6"
1/4
2.0
1/5
Low
1.7
1/6
1.5
M2-R22602
1/2
High
1075 208-230
3.9
12.5 mfd 10
Ball
36"
5.24" 1/2"×5"
1/3
2.2
1/4
Low
1.6
1/5
1.3
M2-R22604
3/4
High
1075 208-230
5.3
15 mfd 12.5 Ball
36"
5.87" 1/2"×6"
1/2
3.0
1/3
Low
1.9
1/4
1.0
Condenser Fan
5.5" Condenser Fan Replacement Motors
Supplied Free In
Every Box
All-Purpose Capacitor
• Multi-Rating Capacitor
• 5, 7.5, 10, 12.5 & 15 MFD
Rotom
Emerson
Genteq
Fasco
Marathon
A.O. Smith
M2-R22601
5464, 5464H
3469, 3469HS
D2826
-
FE6001F
M2-R22603
-
-
-
-
FE6003F
M2-R22600
M2-R22605
5462, 5462H
3465, 3465HS
D2827
X072
FE6000F
M2-R22602
5465, 5465H
3468, 3468HS
-
X076
FE6002F
M2-R22604
-
-
-
-
FE6004F
Cross Reference
