Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
54
C
www.cranepumps.com
Professional Plumbing
inches
(mm)
Series 4SE-DS
2" Spherical Solids Handling
Double Seal
6/05
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
4SE914DS 105019 0.9 120/1 60 1750 A 11.6 21.3 14/3 SJTOW 0.373 (9.5)
4SE924DS 105020 0.9 240/1 60 1750 C 5.9 14.9 14/3 SOW 0.530 (13.5)
4SE994DS 105021 0.9 200-240/3 60 1750 C/F 3.2/3.0 9.8/11.0 14/4 SOW 0.570 (14.5)
4SE944DS 105022 0.9 480/3 60 1750 E 1.5 5.3 14/4 SOW 0.570 (14.5)
4SE954DS 105023 0.9 600/3 60 1750 C 1.0 3.4 14/4 SOW 0.570 (14.5)
4SE1474DS 105028 1.4 200-240/1 60 1750 A/D 7.4/7.0 21.5/25.8 14/3 SOW 0.530 (13.5)
4SE1494DS 105029 1.4 200-240/3 60 1750 B/E 4.8/4.5 13.7/15.4 14/4 SOW 0.570 (14.5)
4SE1444DS 105030 1.4 480/3 60 1750 E 2.2 7.7 14/4 SOW 0.570 (14.5)
4SE1454DS 105031 1.4 600/3 60 1750 F 1.5 7.2 14/4 SOW 0.570 (14.5)
4SE1974DS 105036 1.9 200-240/1 60 1750 A/B 8.8/8.3 21.5/25.8 14/3 SOW 0.530 (13.5)
4SE1994DS 105037 1.9 200-240/3 60 1750 A/B 5.3/5.1 13.7/15.4 14/4 SOW 0.570 (14.5)
4SE1944DS 105038 1.9 480/3 60 1750 B 2.5 7.7 14/4 SOW 0.570 (14.5)
4SE1954DS 105039 1.9 600/3 60 1750 C 1.9 7.2 14/4 SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
OPTIONAL - Moisture sensor cord is 18/5 SOW, 0.470 (12mm) O.D.
OPTIONAL - Moisture & Temperature sensor cord for 3 phase models is 18/5 SOW, 0.470 (12mm) O.D.
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
