SECTION
PAGE
DATE
Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
56
C
Professional Plumbing
Series
4SE-L
2½" Spherical Solids Handling
Double Seal
7/12
inches
(mm)
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 2 HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 1 HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
4SE1926L
133159 1.9
230/1 60 1150
D
8.3
35.0
14/3 SOOW/SOW .53 (13.5)
4SE1996L
133160 1.9 200-230/3 60 1150 E/G 5.8/5.0 26.1/30.0 14/4 SOOW/SOW .57 (14.5)
4SE1946L
133161 1.9
460/3 60 1150
G
2.5
15.0
14/4 SOOW/SOW .57 (14.5)
4SE1956L
133162 1.9
575/3 60 1150
G
2.0
12.0
14/4 SOOW/SOW .57 (14.5)
4SE2826L
133163 2.8
230/1 60 1150
A
13.5
31.0
12/3 SOOW/SOW .61 (15.5)
4SE2896L
133164 2.8 200-230/3 60 1150 F/H 9.2/8.4 38.2/44.0 14/4 SOOW/SOW .57 (14.5)
4SE2846L
133165 2.8
460/3 60 1150
H
4.2
22.0
14/4 SOOW/SOW .57 (14.5)
4SE2856L
133166 2.8
575/3 60 1150
H
3.4
17.6
14/4 SOOW/SOW .57 (14.5)
4SE2824L
133125 2.8
230/1 60 1750
A
12.6
23.0
12/3 SOOW/SOW .61 (15.5)
4SE2894L
133141 2.8 200-230/3 60 1750 D/G 9.2/8.0 35.9/42.7 12/4 SOOW/SOW .68 (17.4)
4SE2844L
133142 2.8
460/3 60 1750
F
4.0
18.0
14/4 SOOW/SOW .57 (14.5)
4SE2854L
133144 2.8
575/3 60 1750
F
3.2
14.4
14/4 SOOW/SOW .57 (14.5)
4SE3724L
133145 3.7
230/1 60 1750
A
20.0
29.0
10/3 SOOW/SOW .66 (16.8)
4SE3794L
133146 3.7 200-230/3 60 1750 B/E 16.1/14.0 35.9/42.7 12/4 SOOW/SOW .68 (17.4)
4SE3744L
133147 3.7
460/3 60 1750
E
7.0
21.3
14/4 SOOW/SOW .57 (14.5)
4SE3754L
133148 3.7
575/3 60 1750
G
5.6
21.6
14/4 SOOW/SOW .57 (14.5)
4SE5024L
133149 5.0
230/1 60 1750
A
28.0
59.0
10/3 SOOW/SOW .66 (16.8)
4SE5094L
133150 5.0 200-230/3 60 1750 B/D 20.9/19.0 48.6/56.0 10/4 SOOW/SOW .72 (18.5)
4SE5044L
133151 5.0
460/3 60 1750
D
9.0
28.0
14/4 SOOW/SOW .57 (14.5)
4SE5054L
131152 5.0
575/3 60 1750
E
8.3
23.0
14/4 SOOW/SOW .57 (14.5)
Moisture/Temperature sensor cord for all models is 18/5 SOOW/SOW, 0.47 (11.9mm) O.D.
4" 125 LB
FLANGE 25.52
(648)
5.24
(133)
15.69
(398)
9.38
(238)
12.62
(321)
6.31
(160)
