Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
46
C
Professional Plumbing
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
Series
3SEV-DS
2" Spherical Solids Handling
Vortex, Double Seal
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SEV514DS
104949 0.5
120/1 60 1750
F
12.0
21.3
14/3 SJTOW 0.375 (9.5)
3SEV524DS
104950 0.5
240/1 60 1750
J
6.3
14.9
14/3 SOW 0.530 (13.5)
3SEV594DS
104951 0.5 200-240/3 60 1750 H/L 3.7/3.8 9.8/11.0 14/4 SOW 0.570 (14.5)
3SEV544DS
104952 0.5
480/3 60 1750
K
1.9
5.3
14/4 SOW 0.570 (14.5)
3SEV554DS
104953 0.5
600/3 60 1750
H
1.4
3.4
14/4 SOW 0.570 (14.5)
3SEV724DS
104958 0.75
240/1 60 1750 G/K 7.1
25.8
14/3 SOW 0.530 (13.5)
3SEV794DS
104959 0.75 200-240/3 60 1750 H/K 4.8/4.6 13.7/15.4 14/4 SOW 0.570 (14.5)
3SEV744DS
104960 0.75
480/3 60 1750
K
2.3
7.7
14/4 SOW 0.570 (14.5)
3SEV754DS
104961 0.75
600/3 60 1750
L
1.6
7.2
14/4 SOW 0.570 (14.5)
3SEV1024DS
104966 1.0
240/1 60 1750 D/G 8.5
25.8
14/3 SOW 0.530 (13.5)
3SEV1094DS
104967 1.0 200-240/3 60 1750 E/H 5.3/5.1 13.7/15.4 14/3 SOW 0.570 (14.5)
3SEV1044DS
104968 1.0
480/3 60 1750
H
2.5
7.7
14/4 SOW 0.570 (14.5)
3SEV1054DS
104969 1.0
600/3 60 1750
J
2.2
7.2
14/4 SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
OPTIONAL - Moisture sensor cord is 18/5 SOW, 0.470 (11.9mm) O.D.
OPTIONAL - Moisture & Temperature sensor cord for 3 phase models is 18/5 SOW, 0.470 (11.9mm) O.D.
inches
(mm)
4/04
