SECTION
PAGE
DATE
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
Submersible Fountain Pumps
1
H
www.cranepumps.com
Professional Plumbing
Series SFU
DISCHARGE ............................... 1¾” (45mm) Hose Connection,
90° Rotation
LIQUID TEMPERATURE .............145°F (63°C) Continuous
VOLUTE.......................................Brass ASTM A4, 85-5-5-5
INTERMEDIATE...........................Brass ASTM A4, 85-5-5-5
HOUSING TUBE .........................Brass, 260 Soft
HOUSING END PIECE ................Brass ASTM A4, 85-5-5-5
SCREEN: Design ....................Area, 264 sq. in. wrap around,
5/32" Dia. mesh
Material ...................304 Stainless Steel
PUMP SUPPORTS ......................Brass
DIAPHRAGM ...............................Buna-N, Pressure Equalized
IMPELLER:
Design: 1/3 & 1/2HP .............Four Vane Open
3/4 & 1HP................Six Vane Open
Material ..................Brass ASTM A4, 85-5-5-5
SHAFT ........................................416 Stainless Steel
O-RINGS .....................................Buna-N
HARDWARE ................................300 Series Stainless Steel
SEAL ............................................Single Mechanical, Carbon/Ceramic/Buna-N
CABLE ENTRY ............................12 ft. (4m) Cord. Pressure gromment
for sealing and strain relief
MOTOR END BEARING .............Single Row, Ball, Oil Lubricated
PUMP END BEARING ...............Sleeve, Oil Lubricated
MOTOR: Design ......................NEMA L, Oil Filled, Squirrel Cage Induction
Insulation ...............Class A
SINGLE PHASE...........................Permanent Split Capacitor (PSC)
Includes Overload Protection in Motor
Series: SFU
1/3 - 1HP, 3450RPM, 60Hz
DESCRIPTION:
THESE PUMP ARE SPECIALLY DESIGNED FOR USE IN
DRAMATIC, DECORATIVE WATER DISPLAYS
4/04
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
Underwriters Laboratories Inc.
File No. E142177
