170
Electrical
Current Relays
9660 Type
Split Phase Motors
Connect jumper wire
between terminals 1 & 2.
23-7
Solid State Relay
Current Relay Selection
Step 1
Identify the last 3 digits of the Current Relay
you are replacing.
Example
3CR-100-*** or 9660-041-***
Step 2
Using the Selection Chart below, determine
what range the last three numbers fit into.
Example
The number 119 is in the 112 to 121 range.
Step 3
Select your replacement relay from the right
hand column, for push-on mounting or the left
hand column, for bracket mounting.
Current Relays
Bracket
Mounting
Pick-up &
Drop out
Push-on
Mounting
23-7
900
23-7
23-1005
901
23-7005
23-1003
903
23-7003
23-1003
904
23-7003
23-1005
905
23-7005
23-1004
906
23-7003
23-7
907
23-7
23-1001
908
23-7001
23-7
909
23-7001
23-7
911
23-7
23-7
913
23-7
23-1002
914
23-7
23-1003
945
23-7003
23-1005
958
23-7005
23-1007
973
23-1007
974
23-1008
975
23-1003
992
23-7003
23-1003
999
23-7003
Selection Chart
Bracket
Mounting
Selection Chart
Push-on
Mounting
23-7
077 to 111 or 200 to 211
23-7
23-1001
112 to 121 or 212 to 221
23-7001
23-1002
122 to 135 or 222 to 235
23-7002
23-1003
136 to 145 or 236 to 245
23-7003
23-1004
146 to 155 or 246 to 255
23-7004
23-1005
156 to 165 or 256 to 265
23-7005
23-1007
171 to 175 or 271 to 275
23-1008
176 to 178 or 276 to 278
23-1009
179 to 184 or 279 to 284
23-1010
185 to 189 or 285 to 289
-
3CR-***-179 or 279
23-7472
This reference should be used as a guide only.
Current Relays
Bracket
Mounting
Pick-up &
Drop out
Push-on
Mounting
23-1008
*79
23-7472
*92
23-7
*93
23-7
23-1009
*97
23-1010
*98
23-7
23-1009
*99
23-1007
901
23-1007
902
23-1008
903
23-7472
23-7
904
23-7
23-7
905
23-7
23-1003
906
23-7
23-1007
907
23-1005
908
23-7005
23-1003
910
23-7
911
23-7
23-1003
913
23-7003
23-1002
921
23-7002
23-1004
923
23-7004
23-1005
925
23-7005
23-1005
927
23-7005
23-7
931
23-7
23-7
932
23-7
* = 1 or 2.
3CR
Type
Split Phase Motors
Connect jumper wire between
terminals 1 & 3
Capacitor Start Motors
Connect capacitor between
terminals 1 & 2.
Capacitor Start Motors
Connect capacitor between
terminals 1 & 3.
23-7
Illustrated
23-7001
Illustrated
23-1001
Illustrated
Relays
