166
Electrical
Auxiliary Switch.
HC-600
Auxiliary Switch.
HC-250
(One Switch)
HC-500
(Two Switches)
Auxiliary Contact Switches
• Clips Directly Onto Either End Of Any 3 or 4 Pole Rotom Contactor
• 1/4" Quick Connect Terminals
• Snap Fast Action Switch
Part #
Continuous
Amps.
Voltage
Rating
Description
Height Width Depth
HC-250
10
300
1 × SPDT, N.O. & N.C.
2.81" 2.61" 0.67"
HC-500
10
300
2 × SPDT, N.O. & N.C.
2.81" 2.61" 0.67"
HC-600*
10
600
2 Contacts × 1 Pole, N.O
(make) or N.C. (break)
2.77" 3.13" 0.70"
* 6-32 Screw Terminal Model Available - Order Part #
HC-600S
Three Pole Contactors
• UL cUL CE Approved
• 30 Amp.= 4 - 1/4" Brass Spade Terminals Per Power Connection
• 40 Amp.= 4 - 1/4" Copper Spade Terminals Per Power Connection
• 50/ 60 Hz
• Dust/Arc Cover Over Contacts With Built-In Test Button
Part #
Full Load
Amps.
Coil Voltage
50/60
Resistive
Amps.
Locked Rotor
Amps.@240V
Height Width Depth
HC-33024
30
24
40
180
2.99" 2.37" 3.75"
HC-330120
30
120
40
180
2.99" 2.37" 3.75"
HC-330240
30
208/240
40
180
2.99" 2.37" 3.75"
HC-34024
40
24
50
240
2.99" 2.37" 3.75"
HC-340120
40
120
50
240
2.99" 2.37" 3.75"
HC-340240
40
208/240
50
240
2.99" 2.37" 3.75"
HC-35024
50
24
65
300
3.12" 2.75" 3.75"
HC-350120
50
120
65
300
3.12" 2.75" 3.75"
HC-350240
50
208/240
65
300
3.12" 2.75" 3.75"
HC-36024
60
24
75
360
3.12" 2.75" 3.75"
HC-360120
60
120
75
360
3.12" 2.75" 3.75"
HC-360240
60
208/240
75
360
3.12" 2.75" 3.75"
Four Pole Contactors
• UL cUL CE Approved
• 30 Amp.= 4 - 1/4" Brass Spade Terminals Per Power Connection
• 40 Amp.= 4 - 1/4" Copper Spade Terminals Per Power Connection
• 50/ 60 Hz
• Dust/Arc Cover Over Contacts With Built-In Test Button
Part #
Full Load
Amps.
Coil Voltage
50/60
Resistive
Amps.
Locked Rotor
Amps.@240V
Height Width Depth
HC-43024
30
24
40
180
2.99"
2.37 3.75
HC-430120
30
120
40
180
2.99"
2.37 3.75
HC-430240
30
208/240
40
180
2.99"
2.37 3.75
HC-44024
40
24
50
240
2.99" 2.37" 3.75"
HC-440120
40
120
50
240
2.99" 2.37" 3.75"
HC-440240
40
208/240
50
240
2.99" 2.37" 3.75"
HC-33024
3 Pole Contactor Illustrated
HC-44024
4 Pole Contactor Illustrated
Definite Purpose Magnetic Contactors
Contactors
