172
Electrical
Totally Enclosed Fan Relays - Heavy Duty
25-90290
Illustrated
2-Pole HVAC Standard Duty Relays
Coil
Voltage
Part #
SPST
Part #
SPDT
Weight
24
25-90290 25-90293
75g
(2.65oz.)
(Approx.)
120
25-90291 25-90294
240
25-90292 25-90295
Contact Rating
- 125/250 VAC
FLA LRA
Inductive
Amps
Resistive
Amps
8 18
8 Amp
Continuous
16 Amp
Continuous
General Purpose Fan Relays - Standard Duty
Features
Designed for switching single
or two speed fan motor, relays,
solenoids, resistive loads in
cooling, heating or general
purpose switching applications.
• Replace WR/ Essex/ RBM &
Mars type 84 models
• Totally enclosed compact design.
• Quiet & reliable operations.
• UL & cUR (file E44211)
• SPST & SPDT models.
• Universal mounting bracket.
Features
Designed for cooling, heating
or general purpose switching
equipment operating heavier loads.
• Replace WR/ Essex/ RBM & Mars
type 184 models
• Totally enclosed compact design.
• Quiet & reliable operations.
• Universal mounting bracket
• UL & cUR (file E44211)
• SPST, SPDT & SPNO/SPNC
models.
Specifications
• Temperature Range: -20°C (-4°F) to 40°C (104°F).
• Mechanical Life: 1,000,000 operations.
• Electrical Life: 100,000 operations (@ 25amp 277VAC Res.)
• Operate Time (typical): 25 ms at nominal coil voltage.
• Release Time (typical): 25 ms at nominal coil voltage.
• Dielectric Strength (at sea level for 1 min.):
- 2500 Vrms coil to contact.
- 1000 Vrms between open contacts.
• Coil Frequency: 50/60 Hz.
• Coil Insulation: Class A (105°C / 221°F).
• Coil Duty Cycle: Continuous.
• Terminals: 1⁄4" quick-connects.
• Contact Material: Silver cadmium oxide.
• Enclosure: Phenolic.
Heavy Duty Relays
Coil
Voltage
SPST
Part #
SPDT
Part #
SPNO-SPNC*
Part #
Weight
24
25-90360 25-90370 25-90380
85g
(2.99 oz.)
(Approx.)
120
25-90362 25-90372 25-90382
240
25-90364 25-90374 25-90384
*Isolated Contacts
Contact Rating
VAC Amps FLA LRA
Inductive
Amps
Resistive
Amps
125VAC
25
14 84 14 Amp Continuous 25 Amp
Continuous
@ 277
VAC
250VAC
8 48 8 Amp Continuous
277VAC
7 42 7 Amp Continuous
Coil Data
Coil
Voltage
Coil
Resistance
DC OHMS
±10%
Coil data
Nominal
Current MA
Coil Data
Nominal
VA Sealed
Inrush
VA
24
77
167
4
4
120
2,000
33
240
7,200
17
Coil Data
Coil
Voltage
Coil
Resistance
DC OHMS
±10%
Nominal
Current
MA
Nominal
VA
Sealed
Inrush
VA
24
90
146
3.5
4
120
2,000
29
240
7,200
15
Specifications
• Temperature Range: -20°C (-4°F) to 40°C (104°F).
• Mechanical Life: 1,000,000 operations.
• Electrical Life: 100,000 operations (@ 16amp 240VAC Res.)
• Operate Time (typical): 25 ms at nominal coil voltage.
• Release Time (typical): 25 ms at nominal coil voltage.
• Dielectric Strength (at sea level for 1 min.):
- 2500 Vrms coil to contact.
- 1000 Vrms between open contacts.
• Coil Frequency: 50/60 Hz.
• Coil Insulation: Class A (105°C / 221°F).
• Coil Duty Cycle: Continuous.
• Terminals: 1⁄4" quick-connects.
• Contact Material: Silver cerium
• Enclosure: Phenolic.
25-90380
Illustrated
Relays
