293
Service Tools
Refrigerant Leak Monitors
Refrigerant
Leak Monitor
Part #
Refrigerant
Replacement
Sensor
Part #
Features
46-RM11
R-11
46-RMX11
•
Sensitivity
: 100 to 1,000 ppm.
•
Accuracy
: ±3% of the setting or ± 25ppm.
•
Audible Alarm
: 85db @ 30cm (1").
•
Visual Alarm
: High intensity LED display.
•
Operating Temperature
: -28°C to 65°C (-20°F
to 150°F).
- Relative humidity 10 to 95% non-condensing.
•
Sensor Module
: 0°C to 65°C (32°F to 150°F).
•
Power
: AC or DC control voltages (sensor
failure indicator).
•
Weight
: 500g (1lbs 2oz).
•
Warranty
: 1 year.
46-RM12
R-12
46-RMX12
46-RM134
R-134a
46-RMX12
46-RM22
R-22
46-RMX12
46-RM404
R-404
46-RMX12
46-RM407
R-407A
46-RMX11
46-RM500
R-500
46-RMX12
46-RM502
R-502
46-RMX12
46-RM507
R-507A
46-RMX12
46-RMPRC
Percloroethylene
46-RMXPRC
RM Gas Monitors & Replacement Sensors
Compact, highly reliable, yet economical refrigerant leak monitoring systems. Designed
to monitor a single refrigerant in a single zone providing early warning of costly and
environmentally damaging refrigerant leakage. Adjustable sensitivity settings between 100 to
1,000 PPM with an auxiliary 1/2HP N.O. and N.C. dry contact control function for operating an
additional alarm or other safety device. Replacement sensors are interchangeable enabling the
replacement of a failed sensor directly in the field without recalibration, minimizing downtime.
Refrigerant Leak Monitors
46-RM
Series
Refrigerant Gas Analyzer
Refrigerant Leak Detection
• One button testing with a total test cycle time of <60 seconds.
• Identifies and measures % of purity of R134a, R12, R22 and
hydrocarbons with 98% accuracy.
• Audible and visible alarms for flammable hydrocarbons.
• Indicates presence of blends and contaminated refrigerants.
• Printer port for record retention.
Refrigerant Gas Analyzer
Part #
Description
53-GA500
Includes:
• One hose assembly for both R12 & R134a.
• Quick connect adapter for R134a.
• 12 V DC battery clamp adapter.
• 12 V DC cigarette lighter adapter.
• Replacement in-line filter.
• Operators manual.
• Carry/ storage case.
•
Sensor Type
- Positive ion emission heated diode.
•
Sensitivity
- Moving probe exceeds SAE standard J1627.
•
Alarm Sensitivity
: Detects all CFC, HRC and HCFC refrigerants:
- Small: 0.5 oz/yr. (R134a), 0.1 oz/yr. (R12)
- Medium: 1.0 oz/yr. (R134a), 0.5 oz/yr. (R12).
- Large: 5.0 oz/yr. (R134a), 3.0 oz/yr. (R12).
•
Leak Alarm
: Audible alarm and visible neon lamp.
•
Operating Temperature
: -32°F to 104°F.
•
Warranty
: Five year.
•
Dimensions:
5.4" × 8" × 2.5".
•
Weight:
6.5 oz.
53-GA500
Illustrated
Automotive
46-RMX11
46-RMX12
Refrigerant Analyzers
