300
Service Tools
Superheat Tube Thermometer Set
Evacuation Core Remover & Superheat Thermometer
Tool Set (J/B)
• Calculate superheat with temperature/ pressure tool.
• Calibrated -58°F to 302°F
• Quarter-turn ball valve shut-off.
• O-ring seals.
02-C32550
Illustrated
Electronic Thermometers
Mini Infrared Temperature Gun
Part #
Description
46-TMINI
• Temperature Range: -20°C to 500°C (-4°F to 932°F).
• Distance To Spot Ratio: 8:1.
• Emissivity: Pre-set at 0.98.
• Accuracy: ±2°C (±3°F) or ±2% of reading.
• Display: 4 digital backlit LCD.
• Resolution: 0.5° C/F°
• Power: Approximately 15 hours (9V alkaline included).
Mini TEMP-SEEKER® Infrared Gun Thermometers
• Instant temperature measurement over a wide range of applications.
• Simple one-handed operation.
• Laser point sighting, backlit display.
• °C or °F select ability.
• Includes leatherette carrying case and battery.
• Automatic power off feature.
Applications
Quickly measure the temperature of:
• Registers
• Ductwork
• Furnaces,
• Evaporators
• Condensers
• Compressors
• Relays
• Manifolds
• Radiators
• Exhaust systems
• Thermostats
• Bearings and more.
46-TMINI
Illustrated
Electronic Thermometers
TEMP-SEEKER™ Multi-Port Digital Thermometers
Multipurpose temperature (°C or °F selectable) measurement instrument with
three remote temperature stations. Measures temperature differential from any
two of the three remote stations. Extra large probe storage area protects the
two 4.5m (15') general purpose probes (46-TMX2G) included with kit.
46-TM150
Part #
Description
46-TM150
Includes: (2) 46-TMX2G.
Specification
46-TM150,TM250,TM250A,TM250CTemp-Seekers
• Temperature Range: -40°C to 150°C (-40°F to 300°F) 0 to 100% RH.
• Accuracy Temperature: 0.1°C (0.2°F) 0°C to 70°C (32°F to 158°F).
• Relative Humidity: ±2% of reading (0 to 100%).
• Dewpoint: ±2% of reading.
• Operation Temperature: 0°C to 60°C (32°F to 140°).
• Display: 3 digits, 15 annunciators 12mm (1⁄2") characters.
• Power: 20 hours continuous use - 9V alkaline battery
46-TM150
Illustrated
Superheat Thermometer Set
Part #
Description
02-C32550
Includes : evacuation, core remover & superheat tool.
Replacement Parts.
Part #
Description
02-C32504
Replacement bit for 02-A32500 & 02-A32525.
Service Thermometers
