285
Service Tools
Automotive Flow-Thru UV Refrigerant Leak Detection
Flow Thru - Portable 50 watt UV Light Kits
Part #
Description
46-UV100
• 50 watt, 12 VDC, 90° UV swivel light.
• In-line flow-thru injector.
• Automotive coupler.
• 1 oz dye included.
• Enhance glasses & case.
Automotive Dye Stick UV Refrigerant Leak Detection
Dye Stick - Portable 50 watt UV Light Kits
Part #
Description
46-UV100UN
• 50 watt, 12 VDC, 90° UV swivel light.
• In-line hand-turn dye stick injector.
• Automotive coupler.
• 1 oz dye included.
• Enhance glasses & case.
Automotive Squeeze Injector UV Refrigerant Leak Detection
Squeeze Injector - Portable 50 watt UV Light Kits
Part #
Description
46-UV300
• 50 watt, 12 VDC, 90° UV swivel light.
• R134a squeeze dye-injector.
• Automotive coupler.
• 6 dye cartridges included.
• Enhance glasses & case.
Flow Thru - Portable A/C UV Light Kits
This economical method of injection uses refrigerant to push dye into
the system through a refillable anodized aluminum in-line injector.
Simply fill the injector with the appropriate amount of universal
Moonshine™ dye (1⁄4 oz. of dye treats 20 oz. lubricant), connect the
injector to the system and refrigerant tank, then open valves to push
the dye into the system.
Hand-Turn Dye Stick Injector - Portable A/C UV Light Kits
The larger disposable pre filled dye stick services up to 25 standard
cars. Simply turn the handle once and 1⁄4 oz of dye is injected into
the A/C system. Dye can be added to low side without recovering
refrigerant. Dye meets and exceeds SAE J 2297 standard for R134a
air conditioning. Works with both PAG, Ester and mineral oils.
Squeeze Injector - Portable A/C UV Light Kits
This design allows technicians to use pre measured, pre filled dye
cartridges and requires no refrigerant to inject dye into the system.
Simply connect to the low or high side and squeeze the trigger.
Standard automotive A/C systems require only a 1/4 of an ounce.
Larger cartridges are available for vans, trucks, buses and refrigerated
trailers.
46-UV100
Illustrated
46-UV100UN
Illustrated
46-UV300
Illustrated
Automotive
Automotive
Automotive
Leak Detectors
