287
Service Tools
Flow-Thru UV Injection Systems
Squeeze Gun Injectors
Dye cartridges ordered separately
Part #
Description
46-UVNJS
• 1⁄4" HVAC squeeze gun only.
• Uses 46-UVS series pre-charged squeeze
cartridges. Order cartridges separately.
46-UVNJSA
• 1⁄4" HVAC squeeze gun only.
• Uses 46-UVS series pre-charged squeeze
cartridges. Order cartridges separately.
• Includes 46-QCL90 coupler.
Automotive
46-UVNJSA
Illustrated
Includes 46-QCL90
46-UVNJS
Illustrated
Dye Stick Injectors
Treat up to 175lbs. of refrigerant (one turn = 7lbs of
refrigerant)
Part #
Description
46-UVSTICK1
• 1⁄4" UV dye injector stick & adapter hose.
• Uses 46-UVSTICK pre-charged dye stick.
46-UVSTICK2
• 1⁄4" UV dye injector stick & adapter hose.
• Uses 46-UVSTICK pre-charged dye stick.
• Includes automotive R134a coupler.
46-UVSTICK
• Replacement dye stick.
Refillable Flow-Thru Injectors
Treat up to 175lbs. of refrigerant (one turn = 7lbs of
refrigerant)
Part #
Description
46-UVNJ
• 1⁄4" in-line dye injector (1/2 oz. capacity)
• Uses 46-UV series pre-charged dye capsule
sticks.
46-UVNJ1234
• In line automotive dye injector.
• Includes R134a coupler.
• Uses bottle dye refills.
46-UVNJ34
• Hand turn in-line automotive dye injector.
• Includes R134a coupler.
• Uses bottle dye refills.
46-UVNJ2
• 1⁄4" hand turn dye injector (1/2 oz. capacity)
• Uses bottle dye refills.
46-TLJ2
• R12 1/4" SAE manifold dye injector.
• Uses bottle dye refills.
46-TLJ4
• R134a 1/2" ACME manifold dye injector.
• Uses bottle dye refills.
Automotive
Automotive
Automotive
Refillable Injectors - 1/4 oz (7.5ml) to 2 oz
(60ml) capacity
46-UVSTICK2
Illustrated
46-UVNJ1234
Illustrated
46-UVNJ34
Illustrated
46-TLJ2
Illustrated
46-UVNJ
Illustrated
46-UVNJ2
Not Illustrated
46-TLJ4
Not Illustrated
Replacement Parts & Accessories
For Refillable Flow-Thru Injectors.
Part #
Description
46-UVNJXOR
(2) Replacement O-rings for 46-UVNJ, UVNJ134, UVNJ1234.
46-UVNJXO
(2) Replacement O-rings for 46-UVNJ2 & UVNJ34.
46-UVXSH
Hose assembly for 46-UVSTICK & UVSTICK2.
46-UVXSHA
Hose assembly for 46-UVSTICK1 & UVSTICK2 with coupler.
46-UVXSTA
3/8" Female × LO side auto coupler adapter for 46-UVSTICK.
Replacement Parts & Accessories - UV Injector Systems
46-UVXSHA
Illustrated
Leak Detectors
