13
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
3.3" Refrigeration Motors
120 Volt
Part # HP RPM Amps Rot Type Encl. Body Shaft
Bearing
Cross Ref
Fig
R3-R326
1/110 1/1550 0.40 CW SP Open 2.09" 1.4"×1/4"
Sleeve
Blanchard, Franklin
1
O6-R230
1/70 1/2800 0.64 CCW SP Open 2.30" 1.3"×1/4"
Sleeve
Coldstream
2
R3-R205
1/35 1/1550 1.20 CW SP Open 2.50" 1.8"×1/4"
Sleeve
Keeprite
3
R3-R360
1/35 1/1550 1.00 CW SP Open 2.60" 1.6"×1/4"
Sleeve
Keeprite
4
R3-R291
1/30 1/1550 1.30 CW SP Open 2.50" 1.6"×1/4"
Sleeve
Keeprite
4
R3-R318
1/25 1/1550 1.50 CW SP Open 2.84" 2.8"×5/16" Sleeve
Bohn
1
R3-R370
1/20 1/1550 0.75 CW PSC Open 3.98" 2.7"×5/16"
Ball
Keeprite
5
US-R90574
1/20 1/1550 1.90 CW SP Open 2.75" 2.48"×5/16" Sleeve
Larkin, Heatcraft
6
R3-R358
1/20 1/1550 2.00 CCW SP Open 3.30" 3.2"×5/16" Sleeve
Blanchard
7
R3-R1052
1/20 1/1550 2.00 CCW SP Open 3.10" 3.2"×5/16"
Ball
Keeprite, Blanchard
8
R3-R368
1/20 1/1550 1.72 CW SP Open 2.80" 2.5"×5/16" Sleeve
Ref Plus
9
US-R90572
1/15 1/1550 1.80 CCW SP Open 3.08" 3.03"×5/16" Sleeve
Bohn, Heatcraft
6
R3-R313
1/15 1/1550 2.30 CCW SP Open 3.60" 3.0"×5/16" Sleeve
Krack, Bohn, Blanchard
10
Fig. 1
Fig. 2
Fig. 3
Fig. 5
Fig. 4
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
115/230 Volt
Part # HP RPM Amps Rot Type Encl. Body Shaft
Bearing
Cross Ref
Fig
US-R91189
1/20 1550 0.9-1.8 CCW SP TE 3.15 1.65"×5/16" Sleeve
Krack
11
US-R90721
1/12 1550 0.6-1.1 REV PSC OPEN 3.59 3.15"×5/16"
Ball
Bohn, Heatcraft, Larkin
12
US-R90671
1/15 1550 1.1-2.2 CW SP OPEN 5.00 2.24"×5/16"
Ball
GE 11 frame replacement
13
US-R90672
1/15 1550 1.1-2.1 CCW SP OPEN 5.0 2.3"×5/16"
Ball
GE 11 frame replacement
13
240 Volt
Part # HP RPM Amps Rot Type Encl. Body Shaft
Bearing
Cross Ref
Fig
R3-R371
1/20 1550 0.38 CW PSC OPEN 3.98"
2.7"×5/16"
Ball
Keeprite
5
US-R90575
1/20 1550 0.89 CW SP OPEN 2.75"
2.48"×5/16"
Sleeve
Larkin, Heatcraft
6
R3-R369
1/20 1550 0.90 CW SP OPEN 2.80"
2.5"×5/16"
Sleeve
Ref Plus
9
R3-R1053
1/20 1550 1.00 CCW SP OPEN 3.10"
3.2"×5/16"
Ball
Keeprite, Blanchard
8
R3-R359
1/18 1500 1.00 CCW SP OPEN 3.35"
2.8"×5/16"
Sleeve
Keeprite, Blanchard
8
US-R90573
1/15 1550 1.20 CCW SP OPEN 3.50"
3.14"×x5/16"
Sleeve
Bohn, Heatcraft
6
R3-R314
1/15 1550 1.30 CCW SP OPEN 3.60"
3.0"×5/16"
Sleeve
Krack, Torin, Bohn, Blanchard
10
US-R91125
1/12 1550 0.50 CW PSC OPEN 3.62"
2.63"×5/16"
Sleeve
Bohn, Heatcraft
5
Fig. 7
Fig. 8
Fig. 9
