OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R5715
15W
1/1550
115
0.37
CW SP 3.5"
3.50"
-
5215879
2
R5720
15W
1/1550
115
0.38
Rev
SP 3.5"
3.50"
-
5212930
3
R109
1/135
1/1550
115
0.55
CW SP 3.3"
1.72"
0.8 Hubless
Evaporator Fan
3
R605
1/65
1/2800
115
0.84
CW SP Skel
0.88"
1.7"×0.1811
Evaporator Fan
4
R3042
1/4
1/1625
230
1.90 CCW PSC/Inc 5.5"
4.80"
2.5"×1/2"
Ball Bearing
5
Part # Watts Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R348
1/15
1/1550
115
1.12
CW PSC 3.3"
4.0"
3.2"×5/16
M1703
7
Tyler
Vanee
Heat Recovery Motor
Unilux
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
DD-029
1/8
5/1000
115
2.60 CCW PSC/INC 5.0"
3.75"
5.0"×1/2"
L350, L450, L600,
DA3E200, DA3F100,
DA3G142, R2299
6
DD-030
1/6
5/950
115
2.60 CCW PSC/INC 5.5"
3.98"
4.4"x1/2"
5KCP39DEV2795
6
Fig.2
Fig.1
Fig.3
Fig.5
Fig.6
Fig.7
Fig.4
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
R500
1/70
1/1550
115
0.66 CCW SP 3.3"
2.35"
1.6"×5/16"
23197211
1
Tweed Steel
