Dual Voltage 370/440V • Dual MFD
370/440 Volt Oval
MFD
370/440 Volt Round
Dimensions
(Millimeters)
Dimensions
(Inches)
OVAL
ROUND
Dimensions
(Inches)
Dimensions
(Millimeters)
Width Depth Height Width Depth Height
Dia. Height Dia. Height
71.0 45.0 65 2.80 1.77 2.56
36-10-5-3744
10/5
36-105R3744
1.65 3.15 42 80
71.0 45.0 65 2.80 1.77 2.56
36-15-3-3744
15/3
36-153R3744
1.78 3.15 45 80
71.0 45.0 65 2.80 1.77 2.56
36-15-5-3744
15/5
36-155R3744
1.78 3.15 45 80
71.0 45.0 65 2.80 1.77 2.56
36-15-103744
15/10
36-1510R3744
1.97 3.54 50 90
71.0 45.0 80 2.80 1.77 3.15
36-20-5-3744
20/5
36-205R3744
1.97 3.54 50 90
71.0 45.0 90 2.80 1.77 3.55
36-20-153744
20/15
36-2015R3744
1.97 4.16 50 105
25/3
36-253R3744
1.97 3.54 50 90
25/4
36-254R3744
1.97 3.54 50 90
71.0 45.0 80 2.80 1.77 3.15
36-25-5-3744
25/5
36-255R3744
1.97 3.54 50 90
25/7.5
36-257R3744
1.97 4.16 50 105
71.0 45.0 95 2.80 1.77 3.74
36-25-103744
25/10
36-2510R3744
1.97 4.16 50 105
30/4
36-304R3744
1.97 4.16 50 105
71.0 45.0 100 2.80 1.77 3.94
36-30-5-3744
30/5
36-305R3744
1.97 4.16 50 105
35/4
36-354R3744
1.97 4.33 50 110
71.0 45.0 100 2.80 1.77 3.94
36-35-5-3744
35/5
36-355R3744
2.17 4.33 55 110
35/7.5
36-357R3744
2.17 4.33 55 110
35/10
36-3510R3744
2.17 4.33 55 110
71.0 45.0 110 2.80 1.77 4.33
36-40-5-3744
40/5
36-405R3744
2.36 4.72 60 120
40/7.5
36-407R3744
2.36 4.72 60 120
40/10
36-4010R3744
2.36 4.72 60 120
45/4
36-454R3744
2.36 4.72 60 120
71.0 45.0 110 2.80 1.77 4.33
36-45-5-3744
45/5
36-455R3744
2.36 4.72 60 120
45/7.5
36-457R3744
2.36 4.71 60 120
50/5
36-505R3744
2.36 5.12 60 130
50/7.5
36-507R3744
2.36 5.12 60 130
50/10
36-5010R3744
2.36 5.12 60 130
55/5
36-555R3744
2.36 5.12 60 130
55/7.5
36-557R3744
2.36 5.12 60 130
55/10
36-5510R3744
2.36 5.12 60 130
60/5
36-605R3744
2.36 5.12 60 130
60/7.5
36-607R3744
2.36 5.12 60 130
60/10
36-6010R3744
2.36 5.12 60 130
80/5
36-805R3744
2.36 5.90 60 150
Higher Voltage Capacitors Can Be Substituted For Lower Voltage Applications.
ROUND
OVAL
NOTE:
CAPACITORS IN SERIES
• MFD rating decreases; Voltage increases.
New MFD Rating =
MFD 1 × MFD 2
MFD 1 + MFD 2
CAPACITORS IN PARALLEL
• MFD increases; Voltage rating stays constant.
(ex. two 5 MFD 370 V capacitors wired in parallel
is the equivalent of a 10 MFD 370 V Capacitor)
New MFD Rating = MFD 1 + MFD 2
• When connected in either series or parallel
it is recommended that capacitors with the
same MFD ratings be used.
• Higher voltages may be substituted for lower
voltages in the same MFD rating.
