OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R2675
1/30
4/1075 208/230 0.40 CCW 2/370 5.0"
3.80" 7.7"×1/2"×7.7"
02024224
5
R52150
1/4
3/1025 208/230 2.00
CW 7.5/370 5.5"
4.30" 4.5"×1/2"×4.2"
02024246
6
Part # HP Spd/RPM Volts Amps Rot
Type Dia
Body
Shaft
Comment
Fig
RB89
23
1/2050
115
0.46
CW SP Skel
10.4"×3.25"×2.8"
-
45mm Blower Kit
4
RB85
23
1/2050
115
0.46
CW SP Skel
10.4"×3.25"×2.8"
-
RB89 Blower Only
4
RB88
35
1/1900
115
0.60
CW SP Skel
15.4"×3.25"×2.8"
-
45mm Blower Kit
4
RB87
35
1/1900
115
0.60
CW SP Skel
15.4"×3.25"×2.8"
-
RB88 Blower Only
4
RF100-2
1/155
1/3000
115
0.50 CCW SP Skel
0.65"
-
c/w Blade & Bracket
3
Singer
Selkirk Metalbestos
Fig.5
Fig.8
Fig.4
Fig.7
Fig.6
Fig.9
Fig.3
Part # Watts Spd/RPM Volts Amps Type Rot
Dia
Body
Shaft
Comment
Fig
RB267
35
1/1800
115
0.75
SP CCW Skel
12.9"×4.3"×3.6"
-
UZY
1
RB67
35
1/1800
115
0.75
SP CCW Skel
12.9"×4.3"×3.6"
-
RB267 BLOWER ONLY 1
RF235
22
1/3100
115
-
SP
-
Axial
-
-
UZY Old BIS1 & BIS2 2
Security
Fig.1
Fig.2
Part # HP Spd/RPM Volts Amps
Rot
Type Dia Body Shaft
Comment
Fig
R2198
1/14
3/820
115
1.30 CCW 7.5/370 5.0"
4.50"
3.4"×1/2"
c/w Plug
7
R2197
1/14
3/820
115
1.30 CCW 7.5/370 5.0"
4.50"
3.4"×1/2"
Plug & 8.37" Bolt Circle 8
R2299
1/8
5/1000
115
2.00 CCW PSC/INC 5.0"
3.30"
4.3"×1/2"
9"&10" Bolt Circle
9
Snyder General
