Butt’s Pumps and Motors - page 1615

124
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R206
1/80
2/1550
115
0.56
CW SP 3.3"
2.09"
1.4"×1/4"
Humidifiers
4
B.D. Waite
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R462
1/8
3/1600
115
0.90
CW 7.5/370 3.3"
4.13" 3.5"×5/16"×3.5
02101
1
R438
1/7
2/1600
115
1.03
CW 4/370 3.3"
4.31"
1.55"×5/16"
01038
2
R366
1/4
3/1630
115
1.68
CW 7.5/370 3.3"
4.78" 2.97"×3/8"×3.0"
02100
1
R422
1/3
3/1690
115
2.89
CW 7.5/370 3.3"
4.93"
2.06"×3/8"
02209
3
Venmar
Make Up Air Unit 3.3" Motor
Fig.3
Fig.1
Fig.2
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R480
1/30
1/1550 208/230 0.80 CCW SP 3.3"
4.00"
2.5"×3/8"
A2001B
6
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R22645
1/8
1/825 208/230 0.90
Rev
PSC
5/370
5.5"
4.30"
4.8"×1/2"
D832, 21276-01
5
R22170
1/5
1/1075 208/230 1.60
Rev
PSC
5/370
5.5"
3.80"
6.0"×1/2"
K136, D746, 442
5
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R5109
2W
1/1550
115
0.25
CW SP 3.5"
2.50"
-
Condenser Fan
7
R859
1/3
3/1100 208/230 1.50 CCW
PSC
5/370
5.5"
3.90" 5.5"×1/2"×5.3"
R.A.C Delco Motors 8
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RGM451
-
1/1.0
115
0.51 CCW SP
-
3.00"
1.1"×3/8"
4514U1-063
9
RGM452
-
1/2.0
115
1.26 CCW SP
-
3.10"
1.1"×3/8"
CDN.COMFORT IND.
V07926AAD9, V002
9
RGM651
-
1/5.5
115
1.00 CCW SP
-
3.25"
1.1"×1/2"
ECM2616
10
Westcan
Weather King
Whirpool - Inglis
Whitefield Auger Motors
Fig.7
Fig.6
Fig.5
Fig.4
Fig.8
Fig.9
Fig.10
