Submersible Non-Clog Pumps
11
D
Professional Plumbing
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
Series SE & SEV-ASP
Pre-Assembled / Kit Simplex Systems
41 Gallon Basin Package Includes:
One - SE411 or SEV412, or SE421
Heavy duty sewage ejector pump
One - Level Control
Mechanical switch molded inside of a waterproof float. Single
control turns pump on and off automatically. Piggy-Back design.
One - Polyethylene Basin
20" (457mm) Dia. x 30" (762mm) Deep, with 4" (102mm) Inlet Hole.
25" (635mm) Dia. x 24" (610mm) Deep, with 4" (102mm) Inlet Hole.
One - Split Cover with Floatree
2" (51mm) vent, 2" (51mm) Discharge and cord openings
One - 2" (51mm) Vertical Compression Check Valve
Sch. 40 Discharge pipe, cover gasket, cover hardware, cord grommet,
discharge and vent grommets also included.
FEATURES:
Floatree design for easy float maintenance; Flange includes
•
provision for optional alarm float.
Split cover allows simplified basin access
•
Sidewall ribs lock basin in place when concrete floor is poured
•
Inlet hubs easily connect to piping with flexible rubber connectors
•
(Provided by others)
Ribbed floor limits pump rotation
•
NOTE
Pre-Assembled units contain water soluable packing inside. There is no
need to remove it.
DESCRIPTION:
SIMPLEX SYSTEMS (ONE PUMP) ARE GOOD FOR
RESIDENTIAL AND COMMERCIAL SEWAGE OR SUMP
APPLICATIONS. THEY ARE DESIGNED TO HANDLE
WASTES FROM LAVATORIES, LAUNDRY TUBS, FLOOR
DRAINS, WATER CLOSETS, ETC., AND WILL PUMP
THE WATER FROM BELOW GROUND "UPHILL" TO THE
SEWER.
