SECTION
PAGE
DATE
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Basins & Accessories
17
F
Professional Plumbing
SWING CHECK VALVES
1-1/2" & 2" PVC
Compression & Solvent Weld
4/04
Models:
Compression: BCV150C
BCV200C
Solvent Weld: BCV150S
BCV200S
inches
(mm)
Illustration shown may NOT represent true product.
The swing check valves are used for preventing backflow of materials
in waste water lines, sump pump disposal lines, sewage lift stations or
ejector systems. Also used where minimum head loss or flow resistance is
required, or in swimming pools, hot tubs, or spa applications.
FEATURES:
• No metalic parts, corrosion resistant.
• Full flow design.
• Angle seat and weighted flapper design for low pressure seal.
• PVC weighted and shielded flapper will retain backpressure up
to 125 PSI.
• Ideal for close working areas, easy pipe alignment.
• Compression ends can be used as union connections.
• Designed for both horizontal or vertical usage.
• Pressure rated 125 PSI @ 72°F.
PART
NO.
MODEL
NO.
TYPE
SIZE
B
C
102163 BCV150C Compression 1.50
(38)
8.50
(216)
3.15
(80)
102164 BCV200C Compression
2
(51)
9.63
(245)
4.23
(107)
073271 BCV150S Solvent Weld 1.50
(38)
5.38
(137)
3.15
(80)
102166 BCV200S Solvent Weld
2
(51)
6.00
(152)
4.23
(107)
Dimensions may vary
.
COMPRESSION
SOLVENT WELD
