Information
AGENCY LISTINGS
UL and CSA
LESSON Electric and Lincoln Motors Fire Pump and Explosion
Proof motors are UL Listed. Other motor types are UL Recognized,
including models with inherent overheating protection as noted
(i.e. thermally protected models). Leeson and Lincoln motors are
also CSA Certified for both explosion proof and non-explosion
proof enclosures.
AC Motors
Non-Explosion Proof UL File No. CSA File No.
NEMA 48-449 Frame E49747 LR2025
NEMA 500 and 5000 Frame — LR2025*
IEC 63-90 Frame E49747 LR2025
IEC 100-280 Frame E49747 LR2025#
Thermally Protected motors E6312 LR2025
Insulation Systems E37900 LR2025
* Does not include coverage for use with VFD
# Domestic product only
Explosion Proof UL File No. CSA File No.
NEMA 56-326 Frame E12044 LR47504
NEMA 364-449 Frame E12044 LR21839
Fire Pump Motors UL File No. CSA File No.
NEMA 143-510 EX5190 LR2025
Class I, Division 2/Zone 2 UL File No. CSA File No.
NEMA 143T-449 250651*
NEMA 48-449, 5000 Frame — LR21839
European ATEX Zone 2 Intertek Certificate No.
NEMA 143-449, IEC 112-280 ITS06ATEX45370
* All Nema Premium motors with a “00” suffix date coded Jan. 2012
and after are suitable for Hazardous Location designation Class I, Div 2,
Groups A, B, C and D and additionally optional Class I, Zone 2, Groups
IIC, IIB, IIA. For all motors dated coded prior to Jan. 2012 - contact Regal
Beloit Canada.
PMDC Motors + Gear Motors
Non-Explosion Proof UL File No. CSA File No.
NEMA 56-145 E49747 LR2025
AC Inverters E161242 #
SpeedMaster SCR Controls E132235 LR41380
FHP Speed Drives E132235 _
ATEX Directive (ATmospheres EXplosibles)
Mandatory by law, the European Union (EU) Directive 94/9/EC
requires that electric motors for use in explosive atmospheres
carry the CE mark, notified body identifier, Ex symbol, equip-
ment group and category, plus the date code. See “European
Installations” for additional details, located on the next page.
NEMA (National Electrical Manufacturers Ass’n)
LEESON Electric and Lincoln Motors’ are manufactured in
accordance with all applicable areas of NEMA standards in
MG1-2006. When applied in accordance with the “Guidelines for
Application of Three Phase Motors on Variable Frequency Drives”,
LEESON Electric and Lincoln Motors’ are in full compliance
with NEMA MG1-2006, Part 31, Section 4.4.2, as pertaining
to voltage spikes. 460 volt motors must withstand voltage spikes
of up to 1426 volts; 575 volt motors must withstand spikes up to
1788 volts. See “Insulation Systems” for additional detail on this
subject. Website:www.nema.org
Commitment to RoHS and WEEE European Directives
European Directive 2002/95/EC “Restriction of Use of Certain
Hazardous Substances” (RoHS) and Directive 2002/96/EC
“Directives on Waste Electrical and Electronic Equipment”
(WEEE) were enacted to control the amount of certain hazardous
substances contained in products shipped into the E.U. Restricted
substances include lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls and polybrominated
dipheynl ethers.
The scope of products covered, affecting motors, is:
UÊ >À}iÊ œÕÃi œ`Ê>««ˆ>˜ViÃ
UÊ-“>Ê œÕÃi œ`Ê>««ˆ>˜ViÃ
UÊ /Ê>˜`ÊÌiiVœ““Õ˜ˆV>̈œ˜ÃÊiµÕˆ«“i˜Ì
UÊ œ˜ÃՓiÀÊiµÕˆ«“i˜Ì
UÊÊ iVÌÀˆV>Ê >˜`Ê iiVÌÀœ˜ˆVÊ ÌœœÃÊ ­iÝVi«ÌÊ >À}iÊ ÃV>iÊ ÃÌ>̈œ˜>ÀÞÊ
and industrial tools)
UÊ/œÞÃ]ʏiˆÃÕÀiÊ>˜`ÊëœÀÌÃÊiµÕˆ«“i˜Ì
UÊ Õ̜“>̈VÊ`ˆÃ«i˜ÃiÀÃ
The Directives do not currently apply to medical devices, monitor-
ing and control instruments, spare parts for the repair or reuse of
electrical and electronic equipment placed on the market before
July 1, 2006, and most military and state security equipment.
Regal Beloit Corporation worked closely with suppliers to assure
that product falling within the scope of these Directives meets the
specified levels of these substances. The Directives took affect
July 1st, 2006 however many products were converted in May
and June. The products converted are motors in NEMA frame
size 145 and below, both AC and DC motors with the following
exceptions:
UÊÊ À>ŽiʓœÌœÀÃʈ˜Êxȇ£{xÊvÀ>“iÊwill have to be ordered specifically
as RoHS compliant.
UÊÊSome motors with specialty electro-mechanical components.
ISO QUALITY CERTIFICATION
Affiliate of The Regal Beloit corporation. We are ISO 9001:2008
and our registrar is NSF-ISR. The certificate number for the corpo-
ration is C0026928-IS2.
leeson.com/Technical Information
Application Information
Continued on next page.
# - UL Certified for Canada under UL File E 1.67242
