SINGLE PHASE INPUT/THREE PHASE OUTPUT
Output Amps
Input
Catalogue
App.
Dimension
HP
230 VAC
Voltage
Number
Wgt.(lbs.)
H x W x D (in.)
1
/
3
1.7
120-240
174603
5
7.5 x 3.9 x 4.35
1
/
2
2.4
120-240
174604
5
7.5 x 3.9 x 4.35
1
4.2
120-240
174605
5
7.5 x 3.9 x 4.35
1
1
/
2
6.0
120-240
174651
5
7.5 x 3.9 x 5.45
SM2 SERIES FLUX
VECTOR
™
DRIVE
With its price, its flexibility and a power range
of up to 25 Hp, the SM2 SERIES FLUX VECTOR™
drive excels in environments where inverter
technology was once considered too costly,
including packaging machinery, food processing
machinery, material handling/conveying systems
and HVAC systems.
The SM2 SERIES FLUX VECTOR™ carries all
the features required by demanding applications
including four modes of operation (V/Hz, Enhanced
V/Hz, Vector Speed, and Torque), high starting torque, auto-tuning,
advanced low-speed control, and dynamic speed regulation.
General Specifications:
s (ORSEPOWER
1 to 25HP (0.75 to 18.5kW)
s 3UPPLY 0OWER
Single Phase:
120, 208, 220 or 240VAC
Three Phase:
208, 240, 400, 480 or 600VAC
50 / 60 Hz
Motors:
Designed for operation with vector duty rated induction motors rated
for 120, 200, 230, 400, 460 or 575VAC from 0 to 240Hz.
Enclosure:
NEMA1, IP31, -10 to 55°C, 2.5% derate per °C above 40°C
Standard Features
: Easy Set-up and Operation: Program the Vector control
in one of four convenient ways:
s &ROM THE FRONT OF THE DRIVE
s 4HE OPTIONAL REMOTE KEYPAD
s ! 0# 5SING 4ECH,INK 3OFTWARE
(Available free from
)
s 4HE INNOVATIVE %0- 0ROGRAMMER
Modes of operation:
s /PEN ,OOP &LUX 6ECTOR 3PEED OR 4ORQUE
s 6 (Z CONSTANT OR VARIABLE
s %NHANCED 6 (Z WITH !UTO TUNING
Easy to Use Keypad & Display 6-Button Interface:
s 3TART
s 3TOP
s &ORWARD 2EVERSE
s 3CROLL 5P
s 3CROLL $OWN
s %NTER -ODE
Vivid Illumination:
s DIGIT ,%$ DISPLAY
s %ASY TO READ FROM A DISTANCE
s -OVABLE $ECIMAL 0OINT
Acceleration/Deceleration Profiles:
s 4WO )NDEPENDENT !CCEL 2AMPS
s 4WO )NDEPENDENT $ECEL 2AMPS
s ,INEAR OR 3 4YPE
s !UXILIARY 2AMP TO 3TOP
Output Frequency:
s
(Z 3TD
(Z /PTIONAL
Selectable Logic Assertion:
0OSITIVE ,OGIC )NPUT 0.0 CURRENT SOURCING
.EGATIVE ,OGIC )NPUT .0. CURRENT SINKING
Multiple Braking Functions
Loss of Follower Management
Speed Commands:
Keypad, Jog, Floating Point Control
Voltage:
Scalable 0-10 VDC,
Current:
Scalable 4-20 mA, Potentiometer,
8 Preset Speeds
Process Control:
PID Modes: Direct or Reverse Acting,
PID Sleep Mode
115-230 Volts
AC ADJUSTABLE SPEED DRIVES
3- 3%2)%3 35" -)#2/ ).6%24%23 s )0
SINGLE OR THREE PHASE INPUT/THREE PHASE OUTPUT
Output Amps
Input
Catalogue
App.
Dimension
HP
230 VAC
Voltage
Number
Wgt.(lbs.)
H x W x D (in.)
1
/
3
1.7
200-240
174606
5
7.5 x 3.9 x 4.35
1
/
2
2.4
200-240
174607
5
7.5 x 3.9 x 4.35
1
4.2
200-240
174608
5
7.5 x 3.9 x 4.35
1
1
/
2
6
200-240
174609
11
7.5 x 3.9 x 5.45
2
7
200-240
174610
11
7.5 x 3.9 x 5.45
3
9.6
200-240
174611
11
7.5 x 3.9 x 5.45
208-240 Volts
THREE PHASE INPUT/OUTPUT
Output Amps
Input
Catalogue
App.
Dimension
HP
230 VAC
Voltage
Number
Wgt.(lbs.)
H x W x D (in.)
1
1
/
2
6
200-240
174612
11
7.5 x 3.9 x 5.45
2
7
200-240
174613
11
7.5 x 3.9 x 5.45
3
9.6
200-240
174614
11
7.5 x 3.9 x 5.45
5
16.5
200-240
174615
15
7.5 x 3.9 x 5.8
7
1
/
2
23
200-240
174616
18
9.83 x 5.12 x 6.3
10
29
200-240
174617
18
9.83 x 5.12 x 6.3
15
42
200-240
174618
20
12.33 x 6.88 x 8.08
20
54
200-240
174619
20
12.33 x 6.88 x 8.08
1
/
2
1.3/1.1 400-480
174620
5
7.5 x 3.9 x 4.35
1
2.42.1 400-480
174621
5
7.5 x 3.9 x 4.35
1
1
/
2
3.5/3.0 400-480
174622
11
7.5 x 3.9 x 5.45
2
4.0/3.5 400-480
174623
11
7.5 x 3.9 x 5.45
3
5.5/4.8 400-480
174624
11
7.5 x 3.9 x 5.45
5
9.4/8.2 400-480
174625
15
7.5 x 3.9 x 5.8
7
1
/
2
12.6/11 400-480
174626
18
9.83 x 5.12 x 6.3
10
16.1/14 400-480
174627
18
9.83 x 5.12 x 6.3
15
24/21 400-480
174628
20
12.33 x 6.88 x 8.08
20
31/27 400-480
174629
20
12.33 x 6.88 x 8.08
25
39/34 400-480
174630
20
12.33 x 6.88 x 8.08
30
40
400-480
174991
25
12.50 x 6.92 x 8.09
40
52
400-480
174992
30 14.19 x 8.72 x 10.07
1
1.7
480-600
174631
5
7.5 x 3.9 x 4.35
2
2.7
480-600
174632
11
7.5 x 3.9 x 5.45
3
3.9
480-600
174633
11
7.5 x 3.9 x 5.45
5
6.1
480-600
174634
15
7.5 x 3.9 x 5.8
7.5
9
480-600
174635
18
9.83 x 5.12 x 6.3
10
11
480-600
174636
18
9.83 x 5.12 x 6.3
15
17
480-600
174637
20
12.33 x 6.88 x 8.08
20
22
480-600
174638
20
12.33 x 6.88 x 8.08
25
27
480-600
174639
20
12.33 x 6.88 x 8.08
30
32
480-600
174993
25
12.50 x 6.92 x 8.09
40
41
480-600
174994
30 14.19 x 8.72 x 10.07
208-240 Volts
400-480 Volts
480-590 Volts
Voltage Monitoring
Current Monitoring
Real Time Monitoring:
8 register fault history,
Software Version Drive Network ID, DC Bus
Voltage (V), Motor Voltage (V), Output Current (%)
Motor Current (A), Motor Torque (%), Power (kW)
Energy Consumption (kWh), Heatsink
Temperature (°C), 0-10 VDC Input (User Defined),
4-20 mA Input (User Defined) PID Feedback (User
$EFINED !NALOG /UTPUT
,OAD 4ORQUE K7
Network Speed (baud rate), Terminal Continuity,
Keypad Status,
Elapsed Run Time (hours), Elapsed Power on
Time (hours)
Standards:
5, 53! C5, #ANADA #%
(Europe), GOST (Russia/Ukraine) C-Tick
(Australia/New Zealand)
