MS10 Motor Protection
Thermostats
Install one or more thermostats in the motor winding of a
NEMA frame AC motor. These are pilot or signal devices
only, to be used in series with the motor controller or starter
to remove power to the motor. Red motor leads are brought
into the conduit box. Specify normally closed or normally
open contacts. Normally closed contacts connected in series.
Thermostats cannot be installed on explosion proof motors.
Thermistors
Install one or more thermistors on Nema frame AC motor.
Thermistor provides the same protection as thermostats plus
locked rotor, starting overload and single phasing. Must be
connected to thermistor protection relay - sold separately.
MS11 Seals
Install oil seal on shaft end only, may be installed on single,
three phase or direct current motors, not applicable to explo-
sion proof motors
NEMA Frame
56
145T
182-184T
213-215T
254-256T
284-286T
324-326T
364-365T
404-405T
444-445T
MS12 Shaft Modification
Includes modification to existing shaft only, drill and tap one hole on
either end of shaft or mill a flat on the drive end shaft.
List price is per modification. For example, a motor modified by
adding a tapped hole and flat would be priced by adding the list
price twice. Provide details on order. Not applicable to explosion
proof motors.
NEMA Frame
56
145T
182-184T
213-215T
254-256T
284-286T
324-326T
364-365T
404-405T
444-445T
NEMA Frame
42-145T
182-215T
MS13 Washguard™ Requirement
Interior and exterior coatings are used to protect motor against
moisture and corrosion.
Contact factory for pricing on larger frame size.
