144
Specifications are subject to change without notice
Drives
App.
Catalogue
Wgt.
Number
(lbs.)
174190
1
218-001*
<1
*Qty 1
App.
Catalogue
Wgt.
Number
(lbs.)
174189
2
App.
Catalogue
Wgt.
Number
(lbs.)
TS8...
3
DYNAMIC BRAKING RESISTORS
FF
Motor
SM,SM-Plus & SM Vector
App.
Drive
Voltage
Catalogue
Wgt.
HP
Rating
Number
(lbs.)
15-20
208-230V
174144
1
15-20
400-480V
174144
1
15-20
480-590V
174149
1
15-30
400-480V
174145
1
25
480-590V
174140
1
FF
Dynamic Braking Resistors are provided with mounting brackets.
DYNAMIC BRAKING MODULES
WITHOUT RESISTORS
F
Motor
SM,SM-Plus & SM Vector
App.
Drive
Voltage
Catalogue
Wgt.
HP
Rating
Number
(lbs.)
15-20
208-230V
174417
10
15-30
400-480V
174418
10
15-30
480-590V
174419
10
F
Dynamic Braking Resistors are purchased and mounted separately.
DYNAMIC BRAKING MODULES WITH
BUILT-IN DYNAMIC BRAKING RESISTORS
.
Motor
SM,SM-Plus & SM Vector
SM2
App.
Drive
Voltage
Catalogue
Catalogue
Wgt.
HP
Rating
Number
Number
(lbs.)
1/4-1/2
208-230V
174400
174157
2
1/4-1/2
400-480V
174406
174158
2
1 - 1
1
/
2
208-230V
174401
174151
3
1 - 1
1
/
2
400-480V
174407
174152
3
1 - 1
1
/
2
480-590V
174412
174153
3
2 - 3
208-230V
174402
174154
4
2 - 3
400-480V
174408
174155
4
2 - 3
480-590V
174413
174156
4
5
208-230V
174403
174159
5
5
400-480V
174409
174160
5
5
480-590V
174414
174161
5
7
1
/
2
208-230V
174404
174162
6
7
1
/
2
400-480V
174410
174163
6
7
1
/
2
480-590V
174415
174164
6
10
208-230V
174405
174165
8
10
400-480V
174411
174166
8
10
480-590V
174416
174167
8
.
Braking Resistors are included with the module and not purchased separately.
ELECTRONIC
PROGRAMMING UNIT
Electronic Programming Unit allows off-line
set-up and replication of the drive’s plug-in
electronic programming module (shown at
right). Excellent for multi-drive applications.
Keypad input and alphanumeric display
simplify programming. RS-232 serial port
allows downloading of configuration files
from personal computer.
EPM BULK PACK
Plug-in electronic programming
modules (EPM). Allow off-line set-up
and replication of program using
Electronic Programming Unit (at left).
Set of 10.
REMOTE KEYPAD
Remote keypad kit for includes
eight-foot connecting cable and
gasket. Mounted in proper enclosure,
the keypad kit will provide up to
NEMA 4 protection.
These keypads
can only be used with Sub-Micro
drives manufactured May, 1999 or
later (date code of 9922 or higher).
REMOTE SPEED POT
Enclosed remote speed pot for manual
control of VFDs. Available in a number
of configurations. Options include:
s
Stop/Start
s
Pushbuttons
s
On/Off Selector
s
Fwd/Rev
3.375 “
2.156 “
Depth: .625”
ACCESSORIES FOR THE
SM & SM2 SERIES DRIVES
Dynamic Braking Components for the
SM & SM2 Series Drives
Dynamic braking is available for the SM, SM-Plus
& Vector and SM2 series drives as a separate
$YNAMIC "RAKING -ODULE ,OWER (0 MODULES HAVE
the control electronics and the dynamic braking
RESISTOR IN ONE CONVENIENT PACKAGE ,ARGER UNITS
require a separate resistor. The modules can be
panel or DIN rail mounted.
Dimensions (inches)
HP
W
D
0.25-1.5
3.1
3.1
2-3
3.1
4.3
5
3.1
5.6
7.5-10
4.2
6.7
AC ADJUSTABLE SPEED DRIVES
SM PLUS SUB-MICRO INVERTERS
App.
Drive
Catalogue
Wgt.
Type
Number
(lbs.)
SM Vector
174191
2
SM Plus
174191
2
SM
174194
2
SM2*
174150
2
* up to 10hp
