POOL PARTS HAYWARD
SP2600X SUPER PUMP SERIES
SKU Number Description List Price Code
1 SPX1600-PN .......... Hand Knob Kit (inc Swivel Nut & Hand Knob) ............$ 17.56 C
2 SPX1600-V.............¼” Drain Plug (1991 and prior) ...................................$ 3.02 C
SPX1700FGV .........¼” Drain Plug with Gasket ..........................................$ 6.98 C
3 SPX1600-R ............ Diffuser Gasket ...........................................................$ 5.38 C
4 SPX1600-T ............. Housing Gasket ..........................................................$ 12.18 C
5 SPX1600-Z-2 .......... Seal Assembly ............................................................$ 25.96 C
6 SPX0125-Z44 .........Motor Cap Screw (Set of 4) ........................................$ 12.74 C
7 SPX2600-EF5 ........ Seal and Motor Plates.................................................$ 78.18 C
8 SPX1600-Z4 ........... Housing Cap Screw ....................................................$ 6.98 C
9 SPX1600-Z52 .........Mounting Foot Cap Screw .........................................$ 6.18 C
(2 per Set - 2 Sets Required)
10 SPX1600-GJ ..........Mounting Feet - Long..................................................$ 49.14 C
(Set Left & Right with Adapter and 4 Cap Screws)
Parts below must be ordered for specific model & H.P.
11 SPX2600-C ............ Impeller, for 1/2 HP .....................................................$ 46.60 C
SPX2605-C ............ Impeller, for 3/4 HP .....................................................$ 48.52 C
SPX2607-C ............ Impeller, for 1 HP ........................................................$ 51.04 C
SPX2610-C ............ Impeller, for 1.5 HP .....................................................$ 51.98 C
SPX2615C.............. Impeller, for 2 HP ........................................................$ 59.46 C
SPX1621-C ............ Impeller, for 2.5 HP .....................................................$ 67.68 C
12 SPX1600-D ............ Strainer Cover, Clear Lexan........................................$ 86.40 C
13 SPX1600-S............. Strainer Cover Gasket ................................................$ 16.20 C
14A SPX1600-AA .......... Pump Housing/Strainer (1½” x 1½”) ...........................$ 373.90 C
14B SPX1620-AA .......... Pump Housing/Strainer (2” x 2”) .................................$ 388.54 C
15 SPX2600-B ............ Diffuser, for 1/2 thru 2 HP............................................$ 47.34 C
SPX1616-B ............ Diffuser, for 2.5 HP only ..............................................$ 51.98 C
17 SPX1600-M ............ Basket .........................................................................$ 17.56 C
1 12 5
15 3
4
11
13
8
7
6
10
24
2
17
9
14A
14B
10
5
23
9
24
20
2
21
3
8
22 7
11
4
19
18
6
1
SP2800X MAX-FLO PUMP SERIES
SKU Number Description List Price Code
18 SPX1250-LA .......... Strainer Cover, Clear Lexan with Gasket ...................$ 58.78 C
(Fits All Models)
19 SPX0125-T ............. Strainer Cover Gasket ................................................$ 9.02 C
20 SPX2800-AA.......... Pump Housing/Strainer accepts ................................$ 323.52 C
Swing Away Knobs (1½” x 1½”)
21 SPX2800-B ............ Diffuser, for all HP’s.....................................................$ 47.34 C
22 SPX0125-F ............. Slinger.........................................................................$ 4.38 C
23 SPX1250-RA.......... Basket (1994 and prior) ..............................................$ 15.64 C
SPX2800-M ............ Basket (1995)..............................................................$ 15.14 C
24 SPX1600-PN .......... Swivel Nut ...................................................................$ 17.56 C
SPX2800-AAC ....... Housing, Max Flow .....................................................$ 410.16 C
